| # | Part Number | Description | Qty | Status |
|---|
| - |
NSS |
NOT SOLD SEPARATE Decal, Maintenance Schedule ANZP 135 HP 4 S
|
1 |
|
| 1 |
8M0047948 |
SCREW (M10 X 1.5 X 60)
|
2 |
superseded
|
| 10 |
8M0057697 |
CUBE RELAY
|
4 |
superseded
|
| 11 |
832969T15 |
FUSE Mini - Blue - 15 Ampere
|
1 |
|
| 11 |
832969T20 |
FUSE Mini - Yellow - 20 Ampere
|
2 |
|
| 11 |
8329692 |
FUSE Mini - Gray - 2 Ampere
|
1 |
superseded
|
| 12 |
8M0047885 |
FUSE COVER With Spares
|
1 |
|
| 13 |
899145 |
CLIP Tie Strap
|
10 |
|
| 14 |
859376 |
CLIP
|
2 |
|
| 15 |
8M0057694 |
ECM 150HP 4S
|
1 |
superseded
|
| 15 |
8M0098625 |
ECM 150HP 4S SeaPro/ ANZP 135HP 4S
|
1 |
superseded
|
| 15 |
8M0230773 |
ECM 105HP Jet
|
1 |
|
| 16 |
8M0057698 |
HARNESS ASSY Fused
|
1 |
|
| 17 |
8M0033589 |
CABLE ASSY Starter
|
1 |
|
| 18 |
88439A35 |
CABLE ASSEMBLY Battery - Positive
|
1 |
|
| 19 |
88439A26 |
CABLE ASSEMBLY Battery - Negative
|
1 |
|
| 2 |
8M0057693 |
ALTERNATOR
|
1 |
superseded
|
| 20 |
8M0057696 |
HARNESS ASSEMBLY Engine
|
1 |
|
| 21 |
816311T |
TIE STRAP (8.00 Inches)
|
2 |
|
| 22 |
8M0094687 |
DECAL Maintenance Schedule SeaPro
|
1 |
|
| 23 |
8M0098217 |
DECAL Maintenance Schedule Non SeaPro
|
1 |
|
| 24 |
40011145 |
SCREW (M8 x 10) Stainless Steel For Use with Battery Isolator
|
AR |
|
| 3 |
401386 |
NUT (M6) Stainless Steel
|
1 |
|
| 4 |
8M0031641 |
BELT Poly V, 4 Rib
|
1 |
superseded
|
| 5 |
88552525 |
SCREW (M6 x 25 MM) Stainless Steel
|
6 |
superseded
|
| 6 |
65567 |
WASHER (.265 x .750 x .048) Stainless Steel
|
6 |
|
| 7 |
834985 |
GROMMET
|
6 |
superseded
|
| 8 |
856954 |
BUSHING
|
6 |
|
| 9 |
8M0057700 |
COVER Power Center Non SeaPro
|
1 |
superseded
|
| 9 |
8M0099169 |
COVER Power Center SeaPro
|
1 |
|
