| # | Part Number | Description | Qty | Status |
|---|
| - |
821964A8 |
GEARCASE ASSEMBLY (COMPLETE)
|
1 |
disc.
|
| - |
821964A10 |
REBUILD KIT VI SSM
|
1 |
disc.
|
| 1 |
821964A9 |
GEAR HOUSING ASSEMBLY
|
1 |
disc.
|
| 26 |
14834A3 |
PLUG ASSEMBLY Drain - Magnetic
|
2 |
|
| 27 |
805726 |
O-RING Rubber
|
2 |
superseded
|
| 28 |
32561 |
PLUG Pipe - Allen Head (.250-18)
|
1 |
superseded
|
| 29 |
814682 |
STUD (.250 x .812)
|
3 |
|
| 29 |
848534 |
STUD (.250 x 3.18)
|
2 |
|
| 30 |
31524 |
BEARING Roller
|
2 |
|
| 31 |
30932 |
NUT
|
2 |
disc.
|
| 32 |
815488A1 |
GEAR SET (1 PINION/1 DRIVEN)
|
2 |
disc.
|
| 33 |
38657A1 |
SHIM ASSEMBLY
|
3 |
disc.
|
| 34 |
38680A1 |
BEARING ASSEMBLY (LOWER)
|
1 |
superseded
|
| 35 |
87014 |
DRIVESHAFT (FRONT)
|
1 |
disc.
|
| 36 |
60929 |
GEAR
|
1 |
disc.
|
| 37 |
38678A1 |
BEARING ASSEMBLY
|
2 |
superseded
|
| 38 |
87015 |
DRIVESHAFT (REAR)
|
1 |
disc.
|
| 39 |
38681A1 |
BEARING ASSEMBLY
|
1 |
|
| 40 |
60928 |
GEAR
|
1 |
disc.
|
| 41 |
38668A1 |
SHIM SET
|
1 |
|
| 42 |
32069 |
O-RING
|
1 |
|
| 43 |
59386 |
SPACER
|
1 |
disc.
|
| 44 |
35276 |
O-RING (.734 x .139)
|
1 |
|
| 45 |
38631A1 |
BASE ASSEMBLY Water Pump
|
1 |
disc.
|
| 46 |
16977 |
SEAL Oil
|
2 |
|
| 47 |
29596 |
PIN Dowel
|
2 |
superseded
|
| 48 |
848524 |
GASKET
|
1 |
disc.
|
| 49 |
848522 |
SPACER
|
1 |
disc.
|
| 50 |
848528 |
GASKET
|
1 |
|
| 51 |
8485211 |
FACE PLATE
|
1 |
disc.
|
| 52 |
848525 |
GASKET
|
1 |
|
| 53 |
566541 |
KEY
|
1 |
|
| 54 |
899844 |
IMPELLER
|
1 |
superseded
|
| 55 |
848505A1 |
PUMP ASSEMBLY Water (3/4 IN.)
|
1 |
disc.
|
| 56 |
8483211 |
INSERT
|
1 |
disc.
|
| 57 |
55905 |
SEAL Oil
|
1 |
|
| 58 |
88397 |
SEAL (3/4 IN. WATER TUBE)
|
1 |
|
| 59 |
8476852 |
SLEEVE
|
1 |
|
| 60 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
5 |
superseded
|
| 61 |
30506 |
NUT (.250-28)
|
5 |
|
| 62 |
8476506 |
TUBE Water (3/4 IN.)
|
1 |
|
| 63 |
822836 |
WASHER (.445 x .805 x .108)
|
8 |
|
| 64 |
82671015 |
NUT (.437-20) Stainless Steel
|
8 |
superseded
|
| 65 |
30271 |
RING Rubber
|
1 |
superseded
|
