| # | Part Number | Description | Qty | Status |
|---|
| - |
814658A6 |
GASKET SET Engine
|
1 |
disc.
|
| - |
848039A44 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
993163 |
GASKET
|
1 |
|
| 10 |
78968 |
LOCKWASHER Internal (.250)
|
1 |
|
| 11 |
848023 |
THRUST WASHER
|
2 |
|
| 12 |
90766 |
SCREW (#10-32 x .500)
|
3 |
disc.
|
| 13 |
815490A3 |
SHAFT ASSEMBLY Throttle
|
1 |
disc.
|
| 14 |
847882 |
RING Retaining
|
1 |
disc.
|
| 15 |
24800 |
PIN
|
2 |
|
| 16 |
848024 |
BUSHING (W/LIP)
|
1 |
|
| 17 |
8480251 |
BUSHING (W/O LIP)
|
1 |
|
| 18 |
988941 |
SPRING
|
1 |
|
| 19 |
137261 |
LEVER Throttle
|
1 |
disc.
|
| 2 |
816058A6 |
INLET ASSEMBLY Air
|
1 |
superseded
|
| 20 |
41355 |
SET SCREW (#10-32 x .25)
|
1 |
disc.
|
| 21 |
410891 |
SCREW (#8-32 x 1.00)
|
1 |
disc.
|
| 22 |
26995 |
LOCKWASHER (#8) Stainless Steel
|
1 |
|
| 23 |
8162501 |
LINK Throttle
|
1 |
disc.
|
| 24 |
20013 |
NUT (.250-28)
|
1 |
disc.
|
| 25 |
56374 |
NUT (.250-20)
|
1 |
superseded
|
| 26 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
2 |
superseded
|
| 27 |
816742 |
SCREW (.250-20 x 1.250)
|
2 |
|
| 28 |
847881 |
ROD END Right Hand
|
1 |
|
| 29 |
9871510 |
SHUTTER Throttle
|
1 |
|
| 3 |
822715 |
FITTING Elbow
|
1 |
|
| 30 |
848046A1 |
SHIM SET
|
1 |
|
| 4 |
15133 |
FITTING
|
2 |
|
| 5 |
24836 |
CLIP
|
1 |
|
| 6 |
69205 |
C WASHER
|
1 |
superseded
|
| 7 |
62568 |
SCREW (#10-16 x .375)
|
1 |
|
| 8 |
848026A1 |
ACTUATOR
|
1 |
|
| 9 |
32417 |
SCREW (.250-28 x .625)
|
1 |
disc.
|
