| # | Part Number | Description | Qty | Status |
|---|
| - |
814658A6 |
GASKET SET Engine
|
1 |
disc.
|
| - |
848039A44 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
848330T4 |
CRANKSHAFT ASSEMBLY
|
1 |
disc.
|
| 10 |
52035 |
RING Lock (RED)
|
12 |
superseded
|
| 11 |
848201A12 |
RING SET Piston (12 PCS PER A12 SET)
|
1 |
superseded
|
| 12 |
818141A9 |
CONNECTING ROD ASSEMBLY
|
6 |
disc.
|
| 13 |
848475 |
SCREW
|
12 |
|
| 14 |
812876 |
WASHER
|
12 |
superseded
|
| 15 |
821146A1 |
BEARING ASSEMBLY Roller
|
6 |
superseded
|
| 16 |
822553 |
BEARING Needle
|
174 |
superseded
|
| 2 |
67923 |
BEARING Ball (LOWER)
|
1 |
superseded
|
| 3 |
67446 |
RING
|
1 |
|
| 4 |
849819 |
BEARING Ball (UPPER)
|
1 |
disc.
|
| 5 |
54196A6 |
CARRIER ASSEMBLY
|
1 |
|
| 6 |
65800 |
PACKING
|
1 |
|
| 7 |
673772 |
RING
|
7 |
superseded
|
| 8 |
16756A8 |
BEARING ASSEMBLY Roller
|
2 |
superseded
|
| 9 |
827352A13 |
PISTON ASSEMBLY (STARBOARD)
|
3 |
disc.
|
| 9 |
827353A13 |
PISTON ASSEMBLY (PORT)
|
3 |
disc.
|
