| # | Part Number | Description | Qty | Status |
|---|
| - |
814658A6 |
GASKET SET Engine
|
1 |
disc.
|
| - |
848039A44 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
1878715 |
CYLINDER HEAD (26 C.C.)
|
2 |
superseded
|
| 10 |
37562 |
SCREW (.312-18 x 1.00) Stainless Steel
|
4 |
|
| 11 |
687271 |
FITTING (.250-18) 90 Degree - Brass (STARBOARD HEAD)
|
1 |
|
| 12 |
68728 |
FITTING (PORT HEAD)
|
1 |
disc.
|
| 13 |
774572 |
HOSE (48.00 Inches Bulk)
|
1 |
|
| 14 |
816311 |
TIE STRAP (8.00 Inches)
|
3 |
superseded
|
| 15 |
876922 |
BLOCK
|
6 |
superseded
|
| 16 |
815242A3 |
REED KIT
|
6 |
|
| 17 |
823588 |
SCREW (#8-32 x .250) (84 PER ENGINE)
|
14 |
|
| 18 |
903911 |
CLAMP Reed
|
12 |
|
| 19 |
987093 |
PLATE
|
1 |
disc.
|
| 2 |
8228441 |
GASKET
|
2 |
superseded
|
| 20 |
NSS |
NOT SOLD SEPARATE SPACER PLATE (PART OF 818451A2)
|
1 |
|
| 21 |
127754 |
GASKET
|
2 |
|
| 22 |
96529 |
SCREW (.250-20 x 2.00)
|
2 |
disc.
|
| 23 |
848920 |
SCREW (.250-20 x 2.50)
|
16 |
|
| 24 |
822837 |
WASHER
|
14 |
|
| 3 |
63779 |
PIN Dowel (.250 x .625)
|
4 |
|
| 4 |
789451 |
CLAMP
|
1 |
|
| 5 |
822838 |
WASHER (.401 x .745 x .097)
|
24 |
|
| 6 |
98534 |
SCREW (.375-16 x 2.30)
|
24 |
disc.
|
| 7 |
475332 |
WASHER
|
2 |
|
| 8 |
62386 |
GASKET
|
2 |
superseded
|
| 9 |
90390A1 |
COVER KIT
|
2 |
|
