| # | Part Number | Description | Qty | Status |
|---|
| - |
76366A4 |
PANEL ASSEMBLY Electrical
|
1 |
superseded
|
| 1 |
13624 |
IGNITION PLATE
|
1 |
|
| 10 |
65999A3 |
CABLE ASSEMBLY Black
|
1 |
disc.
|
| 11 |
26996 |
LOCKWASHER (#10) Stainless Steel
|
1 |
|
| 12 |
38055 |
SCREW (.190-32 x .620)
|
1 |
disc.
|
| 13 |
26996 |
LOCKWASHER (#10) Stainless Steel
|
1 |
|
| 14 |
42813 |
SCREW (#10-32 X .380)
|
1 |
disc.
|
| 15 |
56720 |
WASHER (.330 x .750 x .060) Stainless Steel
|
3 |
|
| 16 |
19064 |
BUSHING
|
3 |
|
| 17 |
825380 |
GROMMET
|
3 |
superseded
|
| 18 |
814634 |
CLAMP
|
2 |
|
| 19 |
57792 |
WASHER
|
3 |
|
| 2 |
7778A14 |
SWITCHBOX ASSEMBLY
|
2 |
|
| 20 |
78986 |
STUD (.312-18/.312-24 x 1.750)
|
3 |
superseded
|
| 21 |
82670911 |
NUT (.312-24) Stainless Steel
|
1 |
|
| 22 |
816770 |
RECTIFIER
|
1 |
superseded
|
| 23 |
38055 |
SCREW (.190-32 x .620)
|
2 |
disc.
|
| 24 |
26996 |
LOCKWASHER (#10) Stainless Steel
|
3 |
|
| 25 |
45076 |
NUT (#10-32) Brass
|
3 |
|
| 26 |
817109A2 |
SOLENOID ASSEMBLY (#10-32 / .3125-18 Terminals)
|
1 |
|
| 27 |
822179 |
GROMMET
|
2 |
|
| 28 |
818968 |
BUSHING
|
2 |
superseded
|
| 29 |
455611 |
SCREW (.250-20 x 1.120)
|
2 |
|
| 3 |
90815 |
SCREW (#12-24 x 2.250)
|
2 |
disc.
|
| 30 |
65999A2 |
CABLE ASSEMBLY Black
|
1 |
disc.
|
| 31 |
26996 |
LOCKWASHER (#10) Stainless Steel
|
2 |
|
| 32 |
45076 |
NUT (#10-32) Brass
|
2 |
|
| 33 |
34437 |
WASHER
|
2 |
|
| 34 |
67980 |
NUT (.312-18)
|
2 |
superseded
|
| 35 |
60466A10 |
CABLE ASSEMBLY Ground
|
1 |
disc.
|
| 36 |
88439A14 |
CABLE ASSEMBLY Battery - Positive
|
1 |
|
| 36 |
88439A2 |
CABLE ASSEMBLY Battery - Negative
|
1 |
|
| 37 |
76366 |
PLATE
|
1 |
|
| 38 |
66582 |
MONTENTARY SWITCH (STARTER, PRIMER)
|
2 |
|
| 39 |
66581 |
SWITCH FUEL
|
1 |
|
| 4 |
94453 |
BUSHING
|
2 |
disc.
|
| 40 |
856654A2 |
HOUSING ASSEMBLY Switch
|
1 |
|
| 41 |
75095A2 |
CAP
|
1 |
superseded
|
| 42 |
45915 |
TERMINAL BLOCK
|
2 |
|
| 43 |
61393A8 |
WIRE
|
2 |
disc.
|
| 44 |
93940A2 |
HARNESS ASSEMBLY
|
1 |
disc.
|
| 45 |
22875 |
CLIP
|
1 |
|
| 46 |
69205 |
C WASHER
|
1 |
superseded
|
| 47 |
48591 |
SCREW (#10-32 x .500)
|
2 |
disc.
|
| 48 |
62568 |
SCREW (#10-16 x .375)
|
2 |
|
| 49 |
29072 |
SCREW (#10-32 x .625)
|
2 |
disc.
|
| 5 |
94304 |
SPACER
|
2 |
|
| 50 |
96113 |
SCREW (#10-32 x .880) Stainless Steel
|
1 |
|
| 51 |
45812 |
NUT (#10-32) Stainless Steel
|
5 |
superseded
|
| 6 |
60871A10 |
WIRE ASSEMBLY
|
2 |
|
| 7 |
62568 |
SCREW (#10-16 x .375)
|
2 |
|
| 8 |
62310A2 |
CABLE ASSEMBLY
|
1 |
|
| 9 |
45076 |
NUT (#10-32) Brass
|
20 |
|
