CRANKCASE AND CYLINDER HEAD
Parts (26)
| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 95457M |
СИЛОВАЯ ГОЛОВКА В СБОРЕ POWERHEAD ASSEMBLY |
1 | discontinued |
| - | 813475M |
КОМПЛЕКТ ПРОКЛАДОК Силовая головка [M-131232] & Up GASKET SET Powerhead [M-131232] & Up |
1 | discontinued |
| - | 84988M |
КОМПЛЕКТ ПРОКЛАДОК Силовая головка [M-131231] & Below GASKET SET Powerhead [M-131231] & Below |
1 | discontinued |
| 1 | 7856M |
КАРТЕР В СБОРЕ CRANKCASE ASSEMBLY |
1 | discontinued |
| 10 | 82405M |
БОЛТ BOLT |
4 | discontinued |
| 11 | 82214M |
ШАЙБА CYLINDER HEAD BOLT WASHER CYLINDER HEAD BOLT |
4 | discontinued |
| 12 | 84983M |
ПЛАСТИНЧАТЫЙ КЛАПАН В СБОРЕ REED VALVE ASSEMBLY |
1 | discontinued |
| 13 | 84984M |
НАБОР ПЛАСТИНЧАТЫХ КЛАПАНОВ (REED STOP NOT INCLUDED) REED SET (REED STOP NOT INCLUDED) |
1 | discontinued |
| 14 | 84985M |
ПРОКЛАДКА REED VALVE SEAT GASKET REED VALVE SEAT |
1 | discontinued |
| 15 | 84986M |
КРОНШТЕЙН THROTTLE LINKAGE BRACKET THROTTLE LINKAGE |
1 | discontinued |
| 16 | 84987M |
БОЛТ BOLT |
4 | discontinued |
| 17 | 99990M |
РУКАВ DRAIN HOSE DRAIN |
1 | superseded |
| 18 | 82046M |
ЗАЖИМ HOSE CLAMP HOSE |
2 | discontinued |
| 19 | N.S.S. |
Не продается отдельно DECAL-REAR (PART OF 37-810931A90) [M-142377] & Up Not Sold Separate DECAL-REAR (PART OF 37-810931A90) [M-142377] & Up |
1 | |
| 19 | 11908M |
НАКЛЕЙКА REAR [M-142376] & Below DECAL REAR [M-142376] & Below |
1 | discontinued |
| 2 | 81923M |
ПРОБКА PLUG |
1 | discontinued |
| 20 | 95455M |
ЗАЩИТНОЕ ПРИСПОСОБЛЕНИЕ FUEL TANK [M-061112] & Up PROTECTOR FUEL TANK [M-061112] & Up |
1 | discontinued |
| 21 | 95456M |
БОЛТ [M-061112] & Up BOLT [M-061112] & Up |
2 | discontinued |
| 22 | 83577M |
ЗАЖИМ [M-061112] & Up CLAMP [M-061112] & Up |
1 | discontinued |
| 3 | 80107M |
КЛАПАН CHECK VALVE CHECK |
1 | discontinued |
| 4 | 80743M |
ФИТИНГ Слив FITTING Drain |
2 | discontinued |
| 5 | 14214M |
ШТИФТ Штифт PIN Dowel |
2 | discontinued |
| 6 | 82428M |
БОЛТ BOLT |
2 | superseded |
| 7 | 82214M |
ШАЙБА WASHER |
2 | discontinued |
| 8 | 80313M |
ПРОКЛАДКА CYLINDER HEAD GASKET CYLINDER HEAD |
1 | |
| 9 | 9208M |
ГОЛОВКА ЦИЛИНДРА CYLINDER HEAD |
1 | discontinued |
