| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 863057 |
НАСОС PUMP |
1 | |
| 10 | 415825 |
ЗАЖИМ Нейлон CLAMP Nylon |
1 | |
| 2 | 8M0046157 |
КРОНШТЕЙН Air Pump BRACKET Air Pump |
1 | |
| 3 | 8M0046566 |
ПРОБКА Service Point CAP Valve Service Point |
1 | |
| 4 | 863053T |
ВПУСКНОЙ КОЛЛЕКТОР Air MANIFOLD ASSEMBLY Air |
1 | |
| 5 | 4002314 |
ШАЙБА WASHER |
2 | |
| 6 | 864887 |
ВИНТ (M5) SCREW M5 5.50 x 14.0 x 1.5 SS |
2 | |
| 7 | 8630542 |
РУКАВ (Общая длина 40.00"), серый (Cut to 33 Inch Length) HOSE (40.00 Inches Bulk) Grey (Cut to 33 Inch Length) |
2 | superseded |
| 8 | 8M2021609 |
РУКАВ (33"), черный HOSE (33 Inches) Black |
2 | superseded |
| 9 | 79968 |
ВИНТ (№12-11 x 0.750) SCREW (#12-11 x .750) |
2 | |
| NS | 8630561 |
РУКАВ (Общая длина 42.00"), черный (Cut to 28 Inch Length) HOSE (42.00 Inches Bulk) Black (Cut to 28 Inch Length) |
2 |
