| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 8600891 |
РУКАВ Литой HOSE Molded |
1 | |
| 10 | 807661 |
РУКАВ Transom To Power Steering Cooler (Alpha) HOSE Transom To Power Steering Cooler (Alpha) |
1 | |
| 11 | 1743579 |
РУКАВ (Общая длина 96.00") Sea Water Pump To Drive (Bravo) HOSE (96.00 Inches Bulk) Sea Water Pump To Drive (Bravo) |
1 | superseded |
| 12 | 861505 |
ФИТИНГ Drain Tee FITTING Drain Tee |
1 | |
| 13 | 862271A1 |
ОБРАТНЫЙ КЛАПАН CHECK VALVE |
1 | |
| 14 | 8615871 |
КОЛЕНЧАТЫЙ Drain ELBOW Drain |
1 | |
| 15 | 806926A1 |
КОМПЛЕКТ КОЛЕНЧАТОГО ПАТРУБКА Слив ELBOW KIT Drain |
2 | superseded |
| 16 | 806608A1 |
Комплект пробки (0.500-13), королевский синий Fitting PLUG KIT (.500-13) Royal Blue Fitting |
9 | superseded |
| 17 | 32509 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (0.489 x 0.070) O-RING (.489 x .070) |
9 | |
| 18 | 860088 |
ВТУЛКА BUSHING |
4 | superseded |
| 19 | 46982 |
ФИТИНГ (90 градусов) FITTING (90 Degree) |
1 | |
| 2 | 80769440 |
РУКАВ (4.00") Fuel Cooler To Drain Fitting (Cut To Length) HOSE (4.00 Inches) Fuel Cooler To Drain Fitting (Cut To Length) |
1 | superseded |
| 20 | 815504216 |
ЗАЖИМ Червячная передача (диаметр 1.56) Hose CLAMP Worm Gear (1.56 Diameter) Hose |
4 | |
| 21 | 815504222 |
ЗАЖИМ Червячная передача (диаметр 1.98) Hose CLAMP Worm Gear (1.98 DIameter) Hose |
11 | superseded |
| 22 | 815504228 |
ЗАЖИМ Червячная передача Hose CLAMP Worm Gear Hose |
4 | |
| 23 | 863841T |
ТРУБА Вода Brass (Compact Hydralic Steering) TUBE Water Brass (Compact Hydralic Steering) |
1 | |
| 3 | 864578 |
РУКАВ Drain Fitting To Check Valve HOSE Drain Fitting To Check Valve |
1 | |
| 4 | 864579 |
РУКАВ Check Valve To Thermostat Housing HOSE Check Valve To Thermostat Housing |
1 | |
| 5 | 842413 |
РУКАВ Circulating Pump To Drain Elbow HOSE Circulating Pump To Drain Elbow |
1 | disc. |
| 6 | 864703 |
РУКАВ Drain Elbow To Thermostat Housing HOSE Drain Elbow To Thermostat Housing |
1 | disc. |
| 7 | 863459 |
РУКАВ Thermostat Housing To Starboard Manifold HOSE Thermostat Housing To Starboard Manifold |
1 | |
| 8 | 863458 |
РУКАВ Thermostat Housing To Port Manifold HOSE Thermostat Housing To Port Manifold |
1 | |
| 9 | 8080441 |
РУКАВ Литой Sea Pump To Power Steering Cooler (Bravo) HOSE Molded Sea Pump To Power Steering Cooler (Bravo) |
1 |
