| # | Part Number | Description | Qty | Status |
|---|
| - |
810846A06 |
GASKET SET Overhaul
|
1 |
|
| - |
864626A02 |
MARINE LONG BLOCK
|
1 |
disc.
|
| - |
809825 |
RTV SILICONE (3 Ounce Tube) Metallic Blue
|
1 |
|
| - |
342271 |
SEALING COMPOUND (16 Ounce)
|
1 |
superseded
|
| 1 |
862054Q |
BELT
|
1 |
|
| 10 |
35366 |
SCREW
|
8 |
superseded
|
| 11 |
879345T99 |
PUMP ASSEMBLY
|
1 |
superseded
|
| 12 |
810848 |
GASKET
|
1 |
superseded
|
| 13 |
34471 |
SCREW (.312-18 x 1.500)
|
2 |
superseded
|
| 13 |
34505 |
SCREW (.312-18 x .875)
|
2 |
|
| 14 |
815504212 |
CLAMP Worm Gear
|
1 |
|
| 15 |
899871001 |
CAP Rubber
|
1 |
|
| 16 |
8M2001509 |
WHEEL Trigger
|
1 |
|
| 17 |
8M2004565 |
SPACER BLOCK
|
1 |
superseded
|
| 18 |
8283582 |
SENSOR
|
1 |
superseded
|
| 19 |
40011106 |
SCREW (M5 x 13) Stainless Steel
|
2 |
|
| 2 |
55045 |
BALANCER
|
1 |
superseded
|
| 20 |
8M2005187 |
SCREW (.375-24) Hex Flange Trigger Wheel
|
3 |
|
| 3 |
845627 |
SCREW (.500-20 x 2.500)
|
1 |
|
| 4 |
73483T |
PULLEY
|
1 |
|
| 5 |
47277 |
SCREW (.312-24 x .750)
|
4 |
|
| 6 |
39107 |
LOCKWASHER (.312-24)
|
4 |
|
| 7 |
59341A1 |
COVER ASSEMBLY
|
1 |
superseded
|
| 8 |
97335 |
SEAL
|
1 |
|
| 9 |
49953 |
GASKET
|
1 |
superseded
|
