| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 805597A1 |
КРОНШТЕЙН В СБОРЕ BRACKET ASSEMBLY |
2 | |
| 10 | 66658 |
ЛЕПЕСТКОВАЯ ШАЙБА TAB WASHER |
4 | |
| 11 | 66166A4 |
ЦАПФА 4.20 inches TRUNNION 4.20 inches |
4 | |
| 11 | 8M0101775 |
ЦАПФА 5.50 inches TRUNNION 5.50 inches |
4 | |
| 12 | 68102 |
СТОПОРНАЯ ШАЙБА (0.750) Towsport LOCKWASHER (.750) Towsport |
2 | |
| 13 | 8M0104773 |
ОПОРА В СБОРЕ MOUNT ASSEMBLY |
4 | |
| 14 | 8M0087853 |
ГАЙКА (.750-16) Raw Water Cooling NUT (.750-16) Raw Water Cooling |
4 | |
| 15 | 859126 |
ГАЙКА (.750-16) Raw Water Cooling NUT (.750-16) Raw Water Cooling |
4 | |
| 2 | 4007750 |
ВИНТ (M12 x 50) SCREW (M12 x 50) |
2 | |
| 3 | 38829 |
СТОПОРНАЯ ШАЙБА (0.500) LOCKWASHER (.500) |
8 | |
| 4 | 57357 |
ВИНТ (0.437-13 x 2.250) SCREW (.437-13 x 2.250) |
4 | |
| 5 | 18304 |
ГАЙКА Fresh Water Cooling NUT Fresh Water Cooling |
8 | |
| 6 | 82670814 |
ГАЙКА (0.437-14) NUT (.437-14) |
6 | |
| 7 | 8M0107050 |
КРОНШТЕЙН Передняя опора двигателя BRACKET Front Engine Mount |
2 | |
| 8 | 40001195 |
ВИНТ (M10 x 30) SCREW (M10 x 30) |
6 | |
| 9 | 37269 |
ВИНТ (0.437-14 x 2.00) SCREW (.437-14 x 2.00) |
2 |
