| # | Part Number | Description | Qty | Status |
|---|
| - |
814754A00 |
GASKET SET Engine
|
1 |
superseded
|
| 1 |
190506 |
GASKET
|
1 |
|
| 10 |
144791 |
DIAPHRAGM
|
1 |
|
| 11 |
16496 |
DEFLECTOR Water
|
1 |
|
| 12 |
16497A1 |
PLATE
|
1 |
|
| 13 |
78690002 |
GASKET
|
2 |
|
| 14 |
42996 |
SPRING (Stainless Steel)
|
1 |
|
| 15 |
14480 |
POPPET
|
1 |
|
| 16 |
64872 |
GROMMET
|
1 |
|
| 17 |
65848 |
CARRIER
|
1 |
|
| 18 |
991764 |
GASKET
|
1 |
|
| 19 |
850814T4 |
PLATE Exhaust
|
1 |
|
| 2 |
828343A05 |
PLATE ASSEMBLY Exhaust Divider
|
1 |
|
| 20 |
43044 |
PIN Dowel - Without Hole (.375 x .625)
|
2 |
|
| 21 |
8147011 |
SEAL
|
1 |
superseded
|
| 22 |
680101 |
BRACKET
|
1 |
|
| 23 |
878608 |
SCREW (#10-16 x .500)
|
8 |
|
| 24 |
19565002 |
GROMMET
|
1 |
|
| 25 |
20553 |
WASHER (.406 x .734 x .063)
|
4 |
|
| 26 |
69254 |
NUT
|
6 |
|
| 27 |
27132 |
BUSHING
|
1 |
|
| 28 |
66727 |
SCREW (.312-18 x 1.250)
|
1 |
|
| 29 |
68783 |
SCREW (.312-18 x 2.50)
|
1 |
|
| 3 |
814754 |
SEAL (12.50 Inches)
|
1 |
|
| 30 |
898833 |
SCREW (.375-16 x 3.500)
|
3 |
disc.
|
| 31 |
812905T |
BRACKET Front
|
1 |
|
| 32 |
8055571 |
SCREW (.3125-18 x .50)
|
4 |
|
| 33 |
187031 |
WASHER
|
4 |
|
| 34 |
18778001 |
GROMMET
|
4 |
|
| 35 |
18578T09 |
BRACKET ASSEMBLY Rear
|
1 |
|
| 36 |
12602002 |
GROMMET
|
1 |
|
| 37 |
8M0033787 |
PLUG Jet
|
1 |
|
| 4 |
8263561 |
SCREW AND WASHER (.312-18 x 1.500)
|
16 |
|
| 5 |
881190 |
SCREW (.312-18 x 1.00)
|
2 |
|
| 6 |
687291 |
COVER Relief Valve
|
1 |
superseded
|
| 7 |
31984 |
SCREW (.312-18 x 1.375)
|
4 |
|
| 8 |
69570 |
SCREW (#10-16 x .750)
|
1 |
|
| 9 |
76451 |
WASHER
|
1 |
|
