| # | Part Number | Description | Qty | Status |
|---|
| - |
880686T23 |
GEAR HOUSING ASSEMBLY Complete (Long-Standard)
|
1 |
superseded
|
| - |
880686T24 |
GEAR HOUSING ASSEMBLY Complete (X-Long-Standard)
|
1 |
superseded
|
| - |
880686T28 |
GEAR HOUSING ASSEMBLY Complete (Long-Counter Rotation)
|
1 |
disc.
|
| - |
880686T25 |
GEAR HOUSING ASSEMBLY Complete (X-Long-Counter Rotation)
|
1 |
superseded
|
| - |
830749A01 |
SEAL KIT Gear Housing
|
1 |
|
| - |
43026Q06 |
REPAIR KIT Water Pump Impeller
|
1 |
superseded
|
| - |
817275A08 |
REPAIR KIT Water Pump-Upper
|
1 |
|
| 1 |
880687T01 |
GEAR HOUSING ASSEMBLY Basic
|
1 |
disc.
|
| 10 |
806327 |
SCREW (.437-14 x 1.750)
|
1 |
superseded
|
| 11 |
881866 |
FITTING
|
1 |
|
| 12 |
880703A1 |
COVER ASSEMBLY
|
1 |
superseded
|
| 13 |
8164641 |
SEAL Oil
|
1 |
superseded
|
| 14 |
896522 |
O-RING (799 x .103)
|
1 |
|
| 15 |
8M0046563 |
RING Retaining
|
1 |
|
| 16 |
40011128 |
SCREW (M6 x 20) Stainless Steel
|
4 |
superseded
|
| 17 |
77674 |
WASHER (.35 x .75 x .12)
|
1 |
|
| 18 |
880729 |
GASKET
|
1 |
|
| 19 |
824145 |
SHIFT SHAFT
|
1 |
|
| 2 |
821526001 |
FILLER BLOCK
|
1 |
|
| 20 |
NSS |
NOT SOLD SEPARATE Pinion Gear (Part of 43-880709A02)
|
1 |
|
| 21 |
35921 |
NUT (.625-18)
|
|
|
| 22 |
92721 |
WASHER (.965 x .630)
|
1 |
|
| 23 |
42647A1 |
BEARING ASSEMBLY Roller
|
1 |
|
| 24 |
895835 |
DRIVESHAFT (Long)
|
1 |
|
| 24 |
895836 |
DRIVESHAFT (X-Long)
|
1 |
|
| 25 |
884327A02 |
SHIM/BEARING ASSEMBLY
|
1 |
|
| 26 |
38657A1 |
SHIM ASSEMBLY
|
AR |
disc.
|
| 27 |
NSS |
NOT SOLD SEPARATE Roller Bearing Assembly
|
1 |
|
| 28 |
NSS |
NOT SOLD SEPARATE Cup
|
1 |
|
| 29 |
NSS |
NOT SOLD SEPARATE Roller Bearing Assembly
|
1 |
|
| 3 |
43044 |
PIN Dowel - Without Hole (.375 x .625)
|
2 |
|
| 30 |
NSS |
NOT SOLD SEPARATE Cup
|
1 |
|
| 31 |
8245191 |
RETAINER
|
1 |
|
| 32 |
817275A09 |
HOUSING Water Pump-Complete
|
1 |
|
| 33 |
861415A1 |
SEAL KIT
|
1 |
|
| 34 |
40011128 |
SCREW (M6 x 20) Stainless Steel
|
4 |
superseded
|
| 35 |
43026T2 |
IMPELLER
|
1 |
|
| 36 |
8172761 |
FACEPLATE
|
1 |
superseded
|
| 37 |
880719 |
RING Retaining
|
1 |
|
| 38 |
8M0007131 |
CARRIER ASSEMBLY Oil Seal
|
1 |
|
| 39 |
896523 |
O-RING (2.175 x .103)
|
1 |
superseded
|
| 4 |
826134Q |
ANODE
|
1 |
|
| 40 |
NSS |
NOT SOLD SEPARATE Oil Seal
|
1 |
|
| 41 |
NSS |
NOT SOLD SEPARATE Oil Seal
|
1 |
|
| 42 |
43037 |
KEY
|
1 |
superseded
|
| 43 |
8172771 |
GASKET Water Pump, Upper
|
1 |
|
| 44 |
430331 |
GASKET
|
1 |
|
| 45 |
85944975 |
TUBING (72.00 Inches Bulk) (Cut to 7 Inches) (Long)
|
1 |
|
| 45 |
85944975 |
TUBING (72.00 Inches Bulk) (Cut to 12 Inches) (X-Long)
|
1 |
|
| 5 |
4000333 |
SCREW (M6 x 40)
|
1 |
|
| 6 |
401386 |
NUT (M6) Stainless Steel
|
1 |
|
| 7 |
79953A04 |
PLUG ASSEMBLY (.375-16 x .250)
|
1 |
|
| 8 |
830749 |
SEAL
|
1 |
superseded
|
| 9 |
76214T5 |
ANODE KIT (Mercury)
|
1 |
|
| 9 |
76214Q5 |
ANODE KIT (Quicksilver)
|
1 |
|
