| # | Part Number | Description | Qty | Status |
|---|
| - |
896142A06 |
GASKET SET Powerhead
|
1 |
superseded
|
| - |
896499A07 |
LONG BLOCK ASSEMBLY
|
1 |
disc.
|
| 1 |
896148 |
STUD (M10 x 175)
|
6 |
superseded
|
| 10 |
896699 |
O-RING (1.78 mm x .08 mm)
|
1 |
|
| 11 |
85978571 |
TUBING (52.00 Inches Bulk) To Water Pressure Sensor (Cut to 21.5 Inches)
|
1 |
|
| 12 |
816311T |
TIE STRAP (8.00 Inches)
|
1 |
|
| 13 |
881879A20 |
SENSOR ASSEMBLY Pressure Water
|
|
superseded
|
| 14 |
892403 |
FITTING
|
1 |
superseded
|
| 15 |
883066 |
CLIP (.865)
|
1 |
|
| 16 |
897598 |
STUD (M8 x 49)
|
2 |
superseded
|
| 17 |
826365 |
NUT (M8)
|
4 |
|
| 18 |
885517A05 |
FITTING ASSEMBLY
|
1 |
|
| 19 |
892077 |
O-RING
|
1 |
|
| 2 |
888997001 |
STUD
|
1 |
superseded
|
| 20 |
896268 |
STUD (M10 x 54)
|
2 |
superseded
|
| 21 |
897599 |
STUD (M8 x 55)
|
2 |
superseded
|
| 22 |
826292 |
NUT (M10) Brass/Nickel Plated
|
2 |
|
| 23 |
856774 |
WASHER (.406 x .750 x .105) Stainless Steel
|
6 |
superseded
|
| 24 |
884412 |
NUT
|
6 |
|
| 25 |
828991T |
CLIP
|
1 |
|
| 3 |
878187 |
SENSOR ASSEMBLY Knock
|
1 |
superseded
|
| 4 |
892086035 |
SCREW (M10 x 35)
|
1 |
|
| 5 |
4002319 |
WASHER
|
1 |
|
| 6 |
896595A01 |
JET ASSEMBLY Oil
|
4 |
superseded
|
| 7 |
888988008 |
CLAMP (34.6 MM)
|
2 |
superseded
|
| 8 |
885544002 |
HOSE
|
1 |
|
| 9 |
896094A01 |
FITTING ASSEMBLY
|
1 |
|
