| # | Part Number | Description | Qty | Status |
|---|
| 1 |
892940T |
ALTERNATOR 70 Ampere
|
1 |
superseded
|
| 10 |
880566014 |
BELT Drive
|
1 |
superseded
|
| 11 |
88552785 |
SCREW (M10 x 85)
|
1 |
superseded
|
| 12 |
4002319 |
WASHER
|
1 |
|
| 13 |
401386 |
NUT (M6) Stainless Steel
|
1 |
|
| 14 |
856583A09 |
CABLE ASSEMBLY
|
1 |
superseded
|
| 15 |
858414A04 |
CABLE ASSEMBLY Brass Braided
|
1 |
|
| 15 |
858414A05 |
CABLE ASSEMBLY Stainless Steel Braided
|
1 |
|
| 16 |
88552516 |
SCREW (M6 x 16 MM) Stainless Steel
|
2 |
superseded
|
| 2 |
885349T05 |
BELT TENSIONER
|
1 |
superseded
|
| 3 |
885349500 |
PULLEY
|
1 |
superseded
|
| 4 |
885349501 |
SCREW
|
1 |
|
| 5 |
855729 |
MOUNT
|
4 |
|
| 6 |
845998 |
WASHER (.406 x 1.250 x .089)
|
8 |
|
| 7 |
88552745 |
SCREW (M10 x 45)
|
5 |
superseded
|
| 8 |
88535303S |
BRACKET Alternator
|
1 |
superseded
|
| 9 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
1 |
superseded
|
