| # | Part Number | Description | Qty | Status |
|---|
| - |
814754A00 |
GASKET SET Engine
|
1 |
superseded
|
| 1 |
8343T10 |
HOUSING ASSEMBLY Driveshaft - Black - Long (Long)
|
1 |
|
| 1 |
813563T1 |
HOUSING Driveshaft - Black - X-Long (X-Long)
|
1 |
|
| 10 |
34933 |
NUT (.437-20) Stainless Steel
|
2 |
superseded
|
| 11 |
67076 |
CLAMP
|
2 |
superseded
|
| 12 |
66727 |
SCREW (.312-18 x 1.250)
|
4 |
|
| 13 |
8M0001130 |
COVER
|
|
superseded
|
| 14 |
88417 |
SCREW (#12-24 x .620)
|
4 |
|
| 15 |
35521 |
NUT
|
4 |
|
| 16 |
48926 |
WASHER
|
1 |
|
| 17 |
34933 |
NUT (.437-20) Stainless Steel
|
1 |
superseded
|
| 18 |
20553 |
WASHER (.406 x .734 x .063)
|
4 |
|
| 19 |
69254 |
NUT
|
4 |
|
| 2 |
56295 |
STUD (.437 x 2.69)
|
2 |
|
| 20 |
828212 |
BOOT Idle Exhaust
|
1 |
superseded
|
| 21 |
64649 |
PLUG
|
1 |
|
| 22 |
991734 |
GASKET
|
1 |
|
| 23 |
66350001 |
SEAL (Lower)
|
1 |
|
| 24 |
18276T02 |
TUBE Exhaust
|
1 |
superseded
|
| 25 |
177261 |
SEAL (Upper)
|
1 |
superseded
|
| 26 |
812834A2 |
EXTENSION ASSEMBLY Exhaust
|
1 |
|
| 27 |
883085 |
STUD (.250 x 1.38) Design-I
|
4 |
superseded
|
| 27 |
8M0047146 |
SCREW (0.25-20 x 1.50) Design-II
|
4 |
|
| 28 |
35044 |
WASHER (.281 x .625 x .065) Stainless Steel Design-I and Design-II
|
4 |
|
| 29 |
888500 |
NUT
|
4 |
|
| 3 |
898831 |
SCREW (.500-20 x 6.220)
|
2 |
|
| 30 |
183076 |
GASKET
|
1 |
|
| 31 |
8590971 |
TUBE Water (Long)
|
1 |
superseded
|
| 31 |
8590972 |
TUBE Water (X-Long)
|
1 |
superseded
|
| 32 |
18233A20 |
PLATE ASSEMBLY Driveshaft Housing
|
1 |
|
| 33 |
8147012 |
SEAL
|
1 |
superseded
|
| 34 |
68011 |
BRACKET
|
1 |
|
| 35 |
878608 |
SCREW (#10-16 x .500)
|
12 |
|
| 36 |
43044 |
PIN Dowel - Without Hole (.375 x .625)
|
2 |
|
| 37 |
38970 |
SEAL
|
1 |
|
| 4 |
88238A10 |
CABLE ASSEMBLY Ground
|
2 |
|
| 5 |
77327 |
MOUNT Lower
|
2 |
|
| 6 |
49339 |
WASHER (.8125)
|
2 |
|
| 7 |
898832 |
NUT (.500-20)
|
2 |
|
| 8 |
41508 |
SCREW (.250-20 x .500) Stainless Steel
|
1 |
|
| 9 |
45176 |
WASHER (.453 x .812 x .105) Stainless Steel
|
2 |
|
