| # | Part Number | Description | Qty | Status |
|---|
| - |
859399T44 |
GEAR HOUSING ASSEMBLY Complete (X-Long)
|
1 |
superseded
|
| - |
859399T38 |
GEAR HOUSING ASSEMBLY Complete (XX-Long)
|
1 |
superseded
|
| - |
816575A4 |
SEAL KIT Gear Housing
|
1 |
|
| 1 |
859399T24 |
GEAR HOUSING ASSEMBLY Complete (Basic)
|
1 |
|
| 10 |
815481 |
THRUST WASHER
|
1 |
|
| 11 |
815480 |
BEARING Thrust
|
1 |
|
| 12 |
855652T1 |
GEAR Reverse
|
1 |
|
| 13 |
15844 |
BEARING ASSEMBLY Roller
|
1 |
|
| 14 |
78962 |
SPRING
|
2 |
|
| 15 |
848878T |
CLUTCH
|
1 |
|
| 16 |
848838 |
PIN Cross
|
1 |
|
| 17 |
78909 |
PIN Detent
|
2 |
|
| 18 |
824111 |
PROPELLER SHAFT
|
1 |
superseded
|
| 19 |
855651A1 |
GEAR SET Forward/Pinion
|
1 |
|
| 2 |
823903 |
SHIFT CRANK
|
1 |
superseded
|
| 20 |
1761514 |
SPACER SHIM (.206) (.206 Inch)
|
AR |
|
| 20 |
1761515 |
SPACER SHIM (.208) (.208 Inch)
|
AR |
|
| 20 |
1761516 |
SPACER SHIM (.210) (.210 Inch)
|
AR |
|
| 20 |
1761517 |
SPACER SHIM (.212) (.212 Inch)
|
AR |
|
| 20 |
1761518 |
SPACER SHIM (.214) (.214 Inch)
|
AR |
|
| 20 |
1761519 |
SPACER SHIM (.216) (.216 Inch)
|
AR |
|
| 20 |
1761520 |
SPACER SHIM (.218) (.218 Inch)
|
AR |
|
| 20 |
1761521 |
SPACER SHIM (.220) (.220 Inch)
|
AR |
|
| 20 |
1761522 |
SPACER SHIM (.222) (.222 Inch)
|
AR |
|
| 20 |
1761523 |
SPACER SHIM (.224) (.224 Inch)
|
AR |
|
| 20 |
1761524 |
SPACER SHIM (.226) (.226 Inch)
|
AR |
|
| 20 |
1761525 |
SPACER SHIM (.228) (.228 Inch)
|
AR |
|
| 20 |
1761526 |
SPACER SHIM (.230) (.230 Inch)
|
AR |
|
| 21 |
815480 |
BEARING Thrust
|
1 |
|
| 22 |
815481 |
THRUST WASHER
|
1 |
|
| 23 |
828831A3 |
ADAPTER ASSEMBLY Bearing
|
1 |
|
| 24 |
814653T |
BEARING ASSEMBLY Needle Rollers
|
1 |
|
| 25 |
18448 |
THRUST WASHER
|
2 |
|
| 26 |
15842 |
BEARING Thrust
|
2 |
|
| 27 |
8182911 |
RACE Thrust
|
2 |
|
| 28 |
814605 |
KEEPER
|
2 |
|
| 29 |
31534 |
O-RING
|
1 |
superseded
|
| 3 |
19755T7 |
SPOOL ASSEMBLY
|
1 |
superseded
|
| 30 |
818290T8 |
CARRIER ASSEMBLY Bearing
|
1 |
|
| 31 |
30956T |
BEARING Needle
|
1 |
|
| 32 |
14077 |
SEAL Oil (INSIDE)
|
1 |
|
| 33 |
76868 |
SEAL (OUTSIDE)
|
1 |
superseded
|
| 34 |
18323 |
TAB WASHER
|
1 |
|
| 35 |
79448 |
RETAINER
|
1 |
superseded
|
| 36 |
52707Q1 |
PROP NUT KIT (.750-16)
|
1 |
|
| 37 |
762145 |
ANODE
|
1 |
superseded
|
| 38 |
66024 |
SCREW (.437-14 x 1.75)
|
1 |
|
| 4 |
NSS |
NOT SOLD SEPARATE Spool
|
1 |
|
| 5 |
NSS |
NOT SOLD SEPARATE Sleeve
|
1 |
|
| 6 |
NSS |
NOT SOLD SEPARATE Cotter Pin
|
1 |
|
| 7 |
44491A1 |
SHIM SET
|
AR |
disc.
|
| 8 |
828830A2 |
ADAPTER ASSEMBLY Bearing
|
1 |
disc.
|
| 9 |
814653T |
BEARING ASSEMBLY Needle Rollers
|
1 |
|
