| # | Part Number | Description | Qty | Status |
|---|
| - |
846859A4 |
PUMP ASSEMBLY Hydraulic
|
1 |
|
| 1 |
846859A1 |
PUMP ASSEMBLY Hydraulic
|
1 |
superseded
|
| 10 |
79091 |
FUSE 20 Ampere
|
1 |
superseded
|
| 11 |
88075 |
RETAINER
|
1 |
|
| 12 |
853654A1 |
SOLENOID
|
2 |
|
| 13 |
41508 |
SCREW (.250-20 x .500) Stainless Steel
|
4 |
|
| 14 |
20110 |
NUT (#10-32)
|
4 |
|
| 15 |
859119 |
NUT (.312-18)
|
4 |
superseded
|
| 16 |
79023A10 |
FUSE ASSEMBLY 110 Ampere
|
1 |
superseded
|
| 17 |
96457 |
WASHER Phenolic (.27 x .81 x .062)
|
1 |
|
| 18 |
21825 |
NUT (.250-28)
|
1 |
|
| 19 |
65999A11 |
CABLE ASSEMBLY
|
1 |
|
| 2 |
818567 |
BRACKET
|
1 |
|
| 20 |
79139A12 |
CABLE ASSEMBLY Red-Positive
|
1 |
|
| 21 |
46265 |
BOOT
|
5 |
|
| 22 |
22753 |
WASHER
|
4 |
|
| 23 |
79139A26 |
CABLE ASSEMBLY Red
|
1 |
|
| 24 |
87760T |
MOUNTING PLATE
|
1 |
|
| 25 |
39349 |
SCREW (.312-18 x .750) Stainless Steel
|
1 |
|
| 26 |
26993 |
LOCKWASHER (.312)
|
1 |
superseded
|
| 27 |
90271 |
SCREW (.375-16 x .62)
|
2 |
|
| 28 |
58643 |
LOCKWASHER (.375)
|
2 |
|
| 29 |
856774 |
WASHER (.406 x .750 x .105) Stainless Steel
|
4 |
superseded
|
| 3 |
38837 |
SCREW (.312-18 x 1.12)
|
1 |
|
| 30 |
87762 |
BRACKET
|
1 |
|
| 31 |
63826 |
SCREW (.375-16 x 2.50)
|
2 |
|
| 32 |
82670912 |
NUT (.375-16) Stainless Steel
|
2 |
|
| 33 |
818200 |
FITTING
|
1 |
|
| 34 |
77366 |
FITTING
|
2 |
|
| 35 |
95084A18 |
CABLE ASSEMBLY Fuse
|
1 |
|
| 36 |
65017A14 |
HARNESS ASSEMBLY
|
1 |
|
| 37 |
848017T4 |
HARNESS ASSEMBLY Trim
|
1 |
|
| 4 |
57792 |
WASHER
|
2 |
|
| 5 |
34948 |
SPACER
|
1 |
|
| 6 |
65999A12 |
CABLE ASSEMBLY Ground
|
1 |
|
| 7 |
79138A9 |
CABLE ASSEMBLY (6.00 Feet) Black-Negative
|
1 |
|
| 8 |
92051 |
SCREW (10-16 x .75)
|
2 |
|
| 9 |
79147A5 |
HARNESS ASSEMBLY
|
1 |
disc.
|
