| # | Part Number | Description | Qty | Status |
|---|
| 1 |
884429T17 |
FUEL RAIL Port
|
1 |
superseded
|
| 10 |
8048311 |
CLAMP
|
4 |
disc.
|
| 11 |
804528 |
INJECTOR
|
6 |
superseded
|
| 12 |
804530 |
O-RING KIT Contains 6 pcs
|
1 |
|
| 13 |
804529 |
O-RING KIT Contains 6 pcs
|
1 |
|
| 14 |
804522 |
CLAMP
|
2 |
disc.
|
| 15 |
804532 |
O-RING KIT (16 Per Kit)
|
1 |
|
| 16 |
804832 |
CLAMP
|
2 |
|
| 17 |
804526 |
SCREW PACKAGE (M5 x 16) (2 Per)
|
4 |
|
| 18 |
804535001 |
COVER
|
1 |
|
| 19 |
804534001 |
SPRING
|
1 |
|
| 2 |
884430T07 |
FUEL RAIL ASSEMBLY Starboard
|
1 |
superseded
|
| 20 |
804533 |
DIAPHRAGM ASSEMBLY
|
1 |
|
| 21 |
804536 |
O-RING
|
1 |
|
| 22 |
804836 |
FITTING
|
1 |
|
| 23 |
804827 |
HOSE
|
1 |
disc.
|
| 24 |
889310 |
HOSE Fuel Supply
|
1 |
disc.
|
| 25 |
889311 |
HOSE Fuel By Pass
|
1 |
disc.
|
| 26 |
888852 |
SEAL Fuel Director
|
1 |
|
| 27 |
884595A02 |
INJECTOR ASSEMBLY Air
|
6 |
superseded
|
| 28 |
804875 |
SEAL KIT
|
1 |
|
| 29 |
828694A1 |
WASHER ASSEMBLY Cupped
|
6 |
|
| 3 |
804830 |
CLAMP
|
4 |
|
| 30 |
859376 |
CLIP Conduit
|
4 |
|
| 31 |
858778 |
STUD (M10 x 91)
|
4 |
superseded
|
| 32 |
826292 |
NUT (M10) Brass/Nickel Plated
|
4 |
|
| 33 |
856880 |
CLAMP Hose (15.3)
|
1 |
superseded
|
| 4 |
804525 |
SCREW PACKAGE (M5 x 8) (2 Per)
|
11 |
superseded
|
| 5 |
883542 |
VALVE ASSEMBLY (.375 Inch Diameter)
|
2 |
superseded
|
| 6 |
804840 |
O-RING KIT
|
1 |
|
| 7 |
805515 |
CAP Shrader Valve - Brass
|
2 |
disc.
|
| 8 |
804835 |
PLUG
|
1 |
|
| 9 |
880816 |
CLAMP
|
1 |
superseded
|
| NS |
804840 |
O-RING KIT
|
1 |
|
