| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 841017A03 |
СИЛОВАЯ ГОЛОВКА В СБОРЕ POWERHEAD ASSEMBLY |
1 | superseded |
| 1 | 85606065 |
ТРУБОПРОВОД (Общая длина 38.00") (Cut to 11.50 Inch Length) TUBING (38.00 Inches Bulk) (Cut to 11.50 Inch Length) |
2 | superseded |
| 10 | 858955 |
СОЕДИНИТЕЛЬ CONNECTOR |
2 | |
| 11 | 816311T |
ЛЕНТОЧНЫЙ ХОМУТ (8.00") TIE STRAP (8.00 Inches) |
4 | |
| 12 | 875283 |
РУКАВ (2.00") HOSE (2.00 Inches) |
1 | |
| 13 | 875284 |
ФИЛЬТР Однорядный FILTER In Line |
1 | superseded |
| 14 | 858870 |
ОБРАТНЫЙ КЛАПАН CHECK VALVE |
6 | |
| 15 | 859230 |
ФИКСАТОР RETAINER |
2 | superseded |
| 16 | 82381455 |
ТРУБОПРОВОД (Общая длина 25.00") (Cut to 22.00 Inch Length) TUBING (25.00 Inches Bulk) (Cut to 22.00 Inch Length) |
1 | |
| 17 | 85583464 |
ТРУБОПРОВОД (Общая длина 34.00") (Cut to 33 Inch Length) TUBING (34.00 Inches Bulk) (Cut to 33 Inch Length) |
1 | disc. |
| 18 | 85606065 |
ТРУБОПРОВОД (Общая длина 38.00") (Cut to 9.50 Inch Length) TUBING (38.00 Inches Bulk) (Cut to 9.50 Inch Length) |
1 | superseded |
| 19 | 56762 |
ЛЕНТОЧНЫЙ ХОМУТ (4.00") TIE STRAP (4.00 Inches) |
6 | |
| 2 | 85606065 |
ТРУБОПРОВОД (Общая длина 38.00") (Cut to 5.00 Inch Length) TUBING (38.00 Inches Bulk) (Cut to 5.00 Inch Length) |
1 | superseded |
| 20 | 85606065 |
ТРУБОПРОВОД (Общая длина 38.00") (Cut To 11.50 Inch Length) TUBING (38.00 Inches Bulk) (Cut To 11.50 Inch Length) |
1 | superseded |
| 21 | 85606065 |
ТРУБОПРОВОД (Общая длина 38.00") (Cut To 11.50 Inch Length) TUBING (38.00 Inches Bulk) (Cut To 11.50 Inch Length) |
1 | superseded |
| 22 | 85606065 |
ТРУБОПРОВОД (Общая длина 38.00") (Cut to 4.00 Inch Length) TUBING (38.00 Inches Bulk) (Cut to 4.00 Inch Length) |
1 | superseded |
| 23 | 816311T |
ЛЕНТОЧНЫЙ ХОМУТ (8.00") TIE STRAP (8.00 Inches) |
3 | |
| 24 | 889440 |
КОЛЕНЧАТЫЙ ELBOW |
2 | disc. |
| 25 | 85606065 |
ТРУБОПРОВОД (Общая длина 38.00") (Cut To 20.50 Inch Length) TUBING (38.00 Inches Bulk) (Cut To 20.50 Inch Length) |
1 | superseded |
| 26 | 85606065 |
ТРУБОПРОВОД (Общая длина 38.00") (Cut to 15.50 Inch Length) TUBING (38.00 Inches Bulk) (Cut to 15.50 Inch Length) |
1 | superseded |
| 27 | 85606065 |
ТРУБОПРОВОД (Общая длина 38.00") (Cut to 7.00 Inch Length) TUBING (38.00 Inches Bulk) (Cut to 7.00 Inch Length) |
2 | superseded |
| 3 | 18206 |
ФИЛЬТР FILTER |
2 | superseded |
| 4 | 85606065 |
ТРУБОПРОВОД (Общая длина 38.00") (Cut to 9.00 Inch Length) TUBING (38.00 Inches Bulk) (Cut to 9.00 Inch Length) |
1 | superseded |
| 5 | 8245021 |
СОЕДИНИТЕЛЬ CONNECTOR |
1 | |
| 6 | 830756109 |
РУКАВ (Общая длина 57.00") (Cut To 7.00 Inch Length) HOSE (57.00 Inches Bulk) (Cut To 7.00 Inch Length) |
1 | superseded |
| 7 | 424254 |
ФИТИНГ FITTING |
1 | superseded |
| 8 | 816311T |
ЛЕНТОЧНЫЙ ХОМУТ (8.00") TIE STRAP (8.00 Inches) |
3 | |
| 9 | 875289 |
РУКАВ HOSE |
1 |
