| # | Part Number | Description | Qty | Status |
|---|
| 1 |
818810T16 |
SWIVEL BRACKET ASSEMBLY
|
1 |
superseded
|
| 10 |
848125 |
RING Retaining - Spiral Lock
|
2 |
|
| 11 |
8407871 |
SWIVEL PIN
|
1 |
superseded
|
| 12 |
92876A10 |
LINK ROD ASSEMBLY
|
1 |
superseded
|
| 13 |
849838 |
SCREW (.375-24 x 1.250)
|
1 |
|
| 14 |
826709113 |
NUT (.375-24) Stainless Steel
|
2 |
superseded
|
| 15 |
37828 |
WASHER (.390 x .625 x .062) Stainless Steel
|
2 |
|
| 16 |
132121 |
SCREW
|
2 |
|
| 17 |
816056 |
WASHER
|
2 |
|
| 18 |
841198A1 |
SENSOR ASSEMBLY Trim [1E050628] & Below
|
1 |
|
| 19 |
852453 |
SCREW (#10-24 x .560) [1E050628] & Below
|
2 |
|
| 2 |
847729 |
SEAL Oil
|
2 |
|
| 3 |
8M0042131 |
BEARING
|
2 |
|
| 4 |
74036 |
FITTING Grease
|
2 |
superseded
|
| 5 |
847728 |
BEARING
|
2 |
|
| 6 |
82203516 |
BEARING (Starboard)(1 Inch)
|
1 |
|
| 6 |
82203522 |
BEARING (Port)(1.375 Inches)
|
1 |
|
| 7 |
82203540 |
BEARING (2.5 Inches)
|
2 |
|
| 8 |
78854 |
WAVE WASHER
|
1 |
|
| 9 |
86580F4 |
YOKE Bottom
|
1 |
disc.
|
