| # | Part Number | Description | Qty | Status |
|---|
| - |
883201A01 |
POWERHEAD ASSEMBLY
|
1 |
disc.
|
| 1 |
859516T08 |
FUEL RAIL (Port)
|
1 |
disc.
|
| 10 |
8048311 |
CLAMP
|
4 |
disc.
|
| 11 |
804841 |
INJECTOR
|
6 |
|
| 12 |
804530 |
O-RING KIT Contains 6 pcs
|
1 |
|
| 13 |
804529 |
O-RING KIT Contains 6 pcs
|
1 |
|
| 14 |
804522 |
CLAMP
|
2 |
disc.
|
| 15 |
880808 |
CLAMP
|
1 |
|
| 16 |
880807T |
REGULATOR Air (Port)
|
1 |
superseded
|
| 17 |
880809 |
O-RING KIT
|
1 |
|
| 18 |
804832 |
CLAMP
|
2 |
|
| 19 |
804526 |
SCREW PACKAGE (M5 x 16) (2 Per)
|
4 |
|
| 2 |
859517T04 |
FUEL RAIL (Starboard)
|
1 |
disc.
|
| 20 |
804535 |
COVER
|
1 |
superseded
|
| 21 |
804534 |
SPRING
|
1 |
|
| 22 |
804533 |
DIAPHRAGM ASSEMBLY
|
1 |
|
| 23 |
804536 |
O-RING
|
2 |
|
| 24 |
804834 |
PLUG (Starboard)
|
1 |
|
| 25 |
804836 |
FITTING
|
1 |
|
| 26 |
804532 |
O-RING KIT
|
1 |
|
| 27 |
884595A01 |
INJECTOR ASSEMBLY Air
|
6 |
superseded
|
| 28 |
804875 |
SEAL KIT Director Injector
|
6 |
|
| 29 |
858778 |
STUD (M10 x 91)
|
4 |
superseded
|
| 3 |
804830 |
CLAMP
|
4 |
|
| 30 |
826292 |
NUT (M10) Brass/Nickel Plated
|
4 |
|
| 31 |
828694A1 |
WASHER ASSEMBLY Cupped
|
6 |
|
| 32 |
828791 |
CLIP
|
4 |
|
| 4 |
804525001 |
SCREW PACKAGE (2 Per)(M5 x 10)
|
16 |
disc.
|
| 5 |
883542 |
VALVE ASSEMBLY (.375 Inch Diameter)
|
2 |
superseded
|
| 6 |
804840 |
O-RING KIT
|
1 |
|
| 7 |
805515 |
CAP Shrader Valve - Brass
|
2 |
disc.
|
| 8 |
804835 |
PLUG (Port)
|
1 |
|
| 9 |
880816 |
CLAMP
|
1 |
superseded
|
