| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8503891 |
LEVER Throttle Control
|
1 |
superseded
|
| 10 |
401386 |
NUT (M6) Stainless Steel
|
1 |
|
| 11 |
814283T6 |
BRACKET ASSEMBLY Anchor
|
1 |
|
| 12 |
98889 |
LATCH
|
1 |
|
| 13 |
42975 |
DRIVE SCREW
|
2 |
|
| 14 |
39519 |
CUP
|
1 |
|
| 15 |
52100 |
WEAR PLATE
|
1 |
|
| 16 |
38279 |
LATCH
|
1 |
superseded
|
| 17 |
69056 |
WASHER (.255 x .620 x .030) Stainless Steel
|
1 |
|
| 18 |
826709109 |
NUT (.250-28) Stainless Steel
|
1 |
|
| 19 |
28782 |
SCREW (.312-18 x .880) Stainless Steel
|
3 |
|
| 2 |
818165 |
SCREW (.375-16 x 1.75)
|
1 |
|
| 20 |
814284 |
GUIDE BLOCK
|
1 |
|
| 21 |
20099 |
SPRING
|
1 |
|
| 22 |
67073A1 |
LINK ROD ASSEMBLY
|
1 |
|
| 23 |
79932A16 |
SHIFT SHAFT ASSEMBLY (Long)
|
1 |
|
| 23 |
79932A18 |
SHIFT SHAFT ASSEMBLY (Short)
|
1 |
disc.
|
| 24 |
24800 |
PIN
|
1 |
|
| 25 |
NSS |
NOT SOLD SEPARATE Lever-Shift Shaft-Upper
|
1 |
|
| 26 |
26856 |
BUSHING
|
1 |
|
| 27 |
29720 |
WAVE WASHER
|
1 |
|
| 28 |
35462 |
WASHER (.2656 x .625 x .0625) Stainless Steel
|
1 |
|
| 29 |
826709109 |
NUT (.250-28) Stainless Steel
|
1 |
|
| 3 |
55164 |
BUSHING
|
1 |
|
| 30 |
889514A01 |
SWITCH
|
1 |
superseded
|
| 31 |
77478 |
SCREW (#6-32 x .875)
|
2 |
|
| 32 |
27882 |
WASHER
|
2 |
|
| 33 |
932481 |
BUSHING Swivel
|
2 |
superseded
|
| 34 |
8508152 |
ROD
|
1 |
|
| 35 |
8562211 |
CAM
|
1 |
|
| 36 |
856895 |
BUSHING
|
1 |
|
| 37 |
856896 |
BEARING
|
1 |
disc.
|
| 38 |
81893440 |
SCREW (M8 x 40)
|
1 |
|
| 39 |
850286A03 |
LEVER/ROLLER KIT Throttle
|
1 |
|
| 4 |
858959 |
SPACER
|
1 |
|
| 40 |
889610 |
ROLLER
|
1 |
superseded
|
| 41 |
56681 |
WASHER (.203 x .500 x .032)
|
1 |
superseded
|
| 42 |
826709104 |
NUT (#8-32) Stainless Steel
|
1 |
|
| 43 |
889354 |
SCREW Special
|
1 |
disc.
|
| 44 |
881992 |
WASHER Spool
|
1 |
disc.
|
| 45 |
69432 |
LOCKWASHER External (#10)
|
1 |
|
| 46 |
881991 |
WASHER Cupped
|
1 |
disc.
|
| 5 |
64022 |
SCREW (.250-20 x 2.125)
|
1 |
|
| 6 |
64015 |
NUT (.250-20)
|
1 |
|
| 7 |
26852 |
CAP Nylon
|
1 |
|
| 8 |
42927 |
INSERT
|
1 |
|
| 9 |
35459 |
WASHER
|
1 |
|
