| # | Part Number | Description | Qty | Status |
|---|
| - |
883201A01 |
POWERHEAD ASSEMBLY
|
1 |
disc.
|
| 1 |
827325T10 |
COVER ASSEMBLY
|
1 |
superseded
|
| 10 |
855756A1 |
BRACKET KIT
|
1 |
disc.
|
| 11 |
803818 |
SLEEVE
|
1 |
disc.
|
| 12 |
1993716 |
SCREW (M6 x 16)
|
4 |
|
| 13 |
8558432 |
PUMP ASSEMBLY
|
1 |
superseded
|
| 14 |
13791 |
CLAMP (15.7)
|
4 |
superseded
|
| 15 |
856778 |
HOSE
|
1 |
disc.
|
| 16 |
855802A1 |
ELBOW
|
1 |
|
| 17 |
856812 |
FITTING
|
1 |
superseded
|
| 18 |
805062 |
O-RING (.530 x .082)
|
1 |
|
| 19 |
856928 |
GROMMET
|
1 |
disc.
|
| 2 |
821555 |
GROMMET
|
2 |
superseded
|
| 20 |
8283582 |
SENSOR
|
1 |
superseded
|
| 21 |
40011107 |
SCREW (M5 x 16) Stainless Steel
|
2 |
|
| 22 |
883080 |
J CLIP
|
2 |
|
| 23 |
817504 |
SCREW (.250-20 x 1.500) Stainless Steel
|
12 |
|
| 24 |
8215832 |
PIN Special (1.5 Inches)
|
1 |
|
| 25 |
881804A01 |
DECAL EPA Label Information (2001)(SEE NOTE)
|
1 |
disc.
|
| 25 |
881804A02 |
DECAL EPA Label Information (2002)(SEE NOTE)
|
1 |
disc.
|
| 25 |
881804A03 |
DECAL EPA Label Information (2003) (SEE NOTE)
|
1 |
disc.
|
| 26 |
61990 |
TIE STRAP (14.00 Inches)
|
1 |
|
| 27 |
88807A27 |
CABLE ASSEMBLY
|
1 |
disc.
|
| 28 |
82130010 |
SCREW (M6 x 10)
|
1 |
|
| 29 |
633003 |
CLAMP
|
1 |
|
| 3 |
853333T |
FILTER
|
1 |
|
| 30 |
8261151 |
CLAMP Connector
|
1 |
|
| 4 |
853352 |
COVER
|
1 |
disc.
|
| 5 |
857101 |
GROMMET
|
1 |
|
| 6 |
855613 |
GROMMET
|
1 |
|
| 7 |
825064 |
DECAL Caution Start in Gear
|
1 |
superseded
|
| 8 |
NSS |
NOT SOLD SEPARATE VAPOR SEPARATOR ASSEMBLY
|
1 |
|
| 9 |
855633T22 |
AIR HANDLER ASSEMBLY (SEE BREAKDOWN ON AIR HANDLER COMPONENTS)
|
1 |
superseded
|
