| # | Part Number | Description | Qty | Status |
|---|
| - |
840444T04 |
AIR HANDLER ASSEMBLY
|
1 |
disc.
|
| - |
832933A01 |
GASKET SET Powerhead
|
1 |
|
| - |
840756A04 |
POWERHEAD ASSEMBLY
|
1 |
disc.
|
| 1 |
840366A5 |
PLATE ASSEMBLY Intake
|
1 |
disc.
|
| 10 |
1993716 |
SCREW (M6 x 16)
|
1 |
|
| 11 |
884522 |
BRACKET MAP Sensor
|
1 |
|
| 12 |
854445 |
SENSOR MAP
|
1 |
|
| 13 |
885342001 |
SENSOR ASSEMBLY
|
1 |
superseded
|
| 14 |
888814 |
O-RING (.351 x .072)
|
1 |
superseded
|
| 15 |
840512 |
CLIP
|
1 |
disc.
|
| 16 |
840546T4 |
CAM ASSEMBLY
|
1 |
disc.
|
| 17 |
932481 |
BUSHING
|
1 |
superseded
|
| 18 |
8235694 |
BALL Threaded
|
1 |
|
| 19 |
40011155 |
SCREW (M8 x 55) Stainless Steel
|
1 |
|
| 2 |
8046801 |
GASKET
|
1 |
|
| 20 |
8807371 |
BUSHING
|
1 |
|
| 21 |
993211 |
FITTING
|
1 |
|
| 22 |
883942 |
SCREW (M4 x 16)
|
2 |
|
| 23 |
840405T1 |
FUEL RAIL
|
1 |
disc.
|
| 24 |
857149T2 |
PUMP ASSEMBLY Oil
|
1 |
superseded
|
| 25 |
81893435 |
SCREW (M8 x 35)
|
3 |
|
| 26 |
855425A06 |
THROTTLE BODY KIT
|
1 |
disc.
|
| 27 |
82130040 |
SCREW (M6 x 40)
|
4 |
|
| 28 |
855426 |
O-RING
|
1 |
|
| 29 |
8533511 |
GROMMET
|
1 |
|
| 3 |
840418T2 |
REED BLOCK ASSEMBLY
|
6 |
superseded
|
| 30 |
858851A03 |
LEVER ASSEMBLY Throttle
|
1 |
|
| 31 |
889610 |
ROLLER
|
1 |
superseded
|
| 32 |
56681 |
WASHER (.203 x .500 x .032)
|
1 |
superseded
|
| 33 |
826709104 |
NUT (#8-32) Stainless Steel
|
1 |
|
| 34 |
889354 |
SCREW Special
|
1 |
disc.
|
| 35 |
881991 |
WASHER Cupped
|
1 |
disc.
|
| 36 |
881992 |
WASHER Spool
|
1 |
disc.
|
| 37 |
69432 |
LOCKWASHER External (#10)
|
1 |
|
| 38 |
56720 |
WASHER (.330 x .750 x .060) Stainless Steel
|
1 |
|
| 39 |
65292 |
J CLIP
|
2 |
superseded
|
| 4 |
849038 |
SCREW (M3 x 5)
|
60 |
|
| 40 |
84044875 |
SCREW (M6 x 75)
|
12 |
disc.
|
| 41 |
4002318 |
WASHER 8.90 x 24.0x 2.4 PL SS
|
3 |
|
| 42 |
855362 |
GROMMET [0T997973] & Below
|
3 |
superseded
|
| 42 |
855362001 |
GROMMET [0T997974] & Up
|
3 |
|
| 43 |
855364 |
BUSHING
|
3 |
|
| 44 |
840506T |
BRACKET
|
1 |
disc.
|
| 45 |
81893440 |
SCREW (M8 x 40)
|
2 |
|
| 46 |
840449 |
CLIP
|
1 |
disc.
|
| 5 |
840447 |
REED PLATE
|
12 |
|
| 6 |
840445A3 |
REED PETAL KIT
|
1 |
superseded
|
| 7 |
8555252 |
SCREW (M6)
|
12 |
|
| 8 |
858539A3 |
PLENUM KIT Air
|
1 |
|
| 9 |
8046793 |
GASKET [0T997973] & Below
|
1 |
superseded
|
| 9 |
804679004 |
GASKET [0T997974] & Up
|
1 |
|
