| # | Part Number | Description | Qty | Status |
|---|
| 1 |
848797T7 |
BOTTOM PAN
|
1 |
|
| 10 |
4002316 |
WASHER (6.60 X 17.0 X 1.5SS)
|
1 |
superseded
|
| 11 |
28635 |
SCREW (.250-20 x .620) Stainless Steel
|
1 |
|
| 12 |
849830T1 |
LATCH
|
1 |
|
| 13 |
849011 |
SCREW (.250-20 x .750)
|
2 |
|
| 14 |
840455T |
PLATE
|
1 |
superseded
|
| 15 |
38601 |
SCREW (.250-28 x 1.250)
|
14 |
|
| 16 |
826709109 |
NUT (.250-28) Stainless Steel
|
14 |
|
| 17 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
14 |
superseded
|
| 18 |
840456 |
GROMMET
|
2 |
disc.
|
| 19 |
8177133 |
GROMMET
|
2 |
|
| 2 |
848810 |
BRACKET Latch
|
1 |
|
| 20 |
690201 |
SCREW (#10-32 x .875)
|
2 |
|
| 21 |
826709106 |
NUT (#10-32) Stainless Steel
|
2 |
superseded
|
| 22 |
849767 |
SEAL
|
2 |
superseded
|
| 23 |
849766 |
SEAL
|
1 |
superseded
|
| 24 |
849765 |
SEAL
|
1 |
superseded
|
| 25 |
8496191 |
BRACE
|
2 |
|
| 26 |
849011 |
SCREW (.250-20 x .750)
|
4 |
|
| 27 |
849751 |
PLUG
|
2 |
disc.
|
| 28 |
8267098 |
NUT (.250-20) Stainless Steel
|
4 |
|
| 29 |
88621 |
RETAINER
|
1 |
disc.
|
| 3 |
28782 |
SCREW (.312-18 x .880) Stainless Steel
|
2 |
|
| 30 |
849831A1 |
LATCH HANDLE ASSEMBLY
|
1 |
superseded
|
| 31 |
843118 |
STUD (.250-20 x 3.45)
|
2 |
|
| 32 |
849832 |
PIN
|
1 |
|
| 33 |
NSS |
NOT SOLD SEPARATE Decal
|
1 |
|
| 34 |
849837 |
SPRING (.360 Outside Diameter) (.360 O.D.)
|
2 |
disc.
|
| 34 |
842776 |
SPRING (.420 Outside Diameter) (.420 O.D.)
|
2 |
|
| 35 |
846673 |
WASHER (.265 x .500 x .060) Stainless Steel
|
2 |
|
| 36 |
8267098 |
NUT (.250-20) Stainless Steel
|
2 |
|
| 37 |
8569901 |
SWITCH Trim
|
1 |
superseded
|
| 38 |
76256 |
NOZZLE
|
1 |
disc.
|
| 39 |
815504104 |
CLAMP Worm Gear
|
1 |
|
| 4 |
814806 |
WASHER (.344 x .688 x .065) Stainless Steel
|
2 |
superseded
|
| 40 |
77653101 |
HOSE (48.00 Inches Bulk)
|
1 |
|
| 41 |
816311T |
TIE STRAP (8.00 Inches)
|
AR |
|
| 42 |
8401441 |
HOSE
|
1 |
disc.
|
| 43 |
821908 |
PLUG
|
1 |
|
| 44 |
840251A1 |
VALVE BODY KIT
|
1 |
|
| 45 |
8219631 |
CHECK VALVE
|
1 |
|
| 46 |
30641 |
O-RING (.299 x .103)
|
1 |
|
| 47 |
821915 |
WASHER
|
1 |
|
| 48 |
848801A1 |
SKIRT
|
1 |
disc.
|
| 49 |
849000 |
NUT
|
6 |
|
| 5 |
812707 |
BUSHING
|
2 |
|
| 50 |
F2030 |
SCREW (.250-20 x 1.250) Stainless Steel
|
6 |
|
| 51 |
848817 |
BOOT
|
1 |
disc.
|
| 52 |
817362 |
CAP
|
1 |
|
| 53 |
126021 |
GROMMET [0T997973] & Below
|
1 |
superseded
|
| 53 |
12602002 |
GROMMET [0T997974] & Up
|
1 |
|
| 54 |
849750 |
GROMMET
|
1 |
|
| 6 |
848985 |
SEAL
|
1 |
|
| 7 |
848815T1 |
HANDLE
|
1 |
|
| 8 |
F2047 |
WASHER Wave
|
1 |
|
| 9 |
889566 |
CAM
|
1 |
superseded
|
