| # | Part Number | Description | Qty | Status |
|---|
| - |
840306T6 |
GEAR HOUSING ASSEMBLY Complete, With Torque Tab
|
1 |
disc.
|
| - |
816575A6 |
SEAL KIT Gear Housing
|
1 |
|
| - |
840389A2 |
PROP HUB KIT
|
1 |
superseded
|
| - |
840382A1 |
SNUBBER STRIP KIT
|
1 |
superseded
|
| 1 |
840307T3 |
GEAR HOUSING ASSEMBLY Basic (Basic) (With Out Torque Tab)
|
1 |
|
| 1 |
840306T3 |
GEAR HOUSING ASSEMBLY Basic, With Torque Tab (Basic) (With Torque Tab)
|
1 |
|
| 44 |
823903 |
SHIFT CRANK
|
1 |
superseded
|
| 45 |
19755T7 |
SPOOL ASSEMBLY
|
1 |
superseded
|
| 46 |
47397A1 |
SHIM SET
|
1 |
|
| 47 |
878087A6 |
GEAR SET Forward/Pinion (1.62)
|
1 |
|
| 47 |
828168T3 |
GEAR SET Forward/Pinion (1.75)
|
1 |
superseded
|
| 48 |
828437A2 |
BEARING ASSEMBLY
|
1 |
|
| 49 |
30895T |
BEARING Needle
|
1 |
|
| 50 |
856823 |
RING Retaining
|
1 |
|
| 51 |
848878T |
CLUTCH
|
1 |
|
| 52 |
78909 |
PIN Detent
|
2 |
|
| 53 |
848838 |
PIN Cross
|
1 |
|
| 54 |
78962 |
SPRING
|
2 |
|
| 55 |
840453A1 |
PROPELLER SHAFT
|
1 |
superseded
|
| 56 |
848880T1 |
GEAR Reverse (1.62)
|
1 |
|
| 56 |
848881A1 |
GEAR Reverse (1.75)
|
1 |
superseded
|
| 57 |
8241081 |
THRUST SPACER
|
1 |
|
| 58 |
88957T |
BEARING Ball
|
1 |
|
| 59 |
681001 |
RING Thrust
|
1 |
|
| 60 |
31534 |
O-RING
|
1 |
superseded
|
| 61 |
848840T1 |
CARRIER ASSEMBLY Bearing
|
1 |
superseded
|
| 62 |
817072 |
BEARING Roller
|
1 |
|
| 63 |
817071 |
RING Snap
|
1 |
|
| 64 |
815565 |
SEAL Oil
|
2 |
|
| 65 |
30281 |
KEY
|
1 |
|
| 66 |
67892A1 |
FITTING KIT Magnetic, Plug Fill/Drain
|
1 |
superseded
|
| 67 |
191832 |
WASHER
|
1 |
superseded
|
| 68 |
79447 |
TAB WASHER
|
1 |
|
| 69 |
79448 |
RETAINER
|
1 |
superseded
|
| 70 |
85344 |
WASHER (.750 Inside Diameter)
|
1 |
|
| 71 |
52707Q1 |
PROP NUT KIT (.750-16)
|
1 |
|
| 72 |
41350 |
SCREW (.437-14 x 2.50) Stainless Steel
|
1 |
|
| 73 |
76214T3 |
ANODE
|
1 |
|
