Fuel System
Parts (16)
| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 840756A01 |
СИЛОВАЯ ГОЛОВКА В СБОРЕ POWERHEAD ASSEMBLY |
1 | superseded |
| 1 | 840429 |
РУКАВ HOSE |
1 | discontinued |
| 10 | 822769 |
СОЕДИНИТЕЛЬ CONNECTOR |
1 | |
| 11 | 85583463 |
ТРУБОПРОВОД (Общая длина 33.00") (Cut to 15.00 Inch Length) TUBING (33.00 Inches Bulk) (Cut to 15.00 Inch Length) |
1 | superseded |
| 12 | 816311T |
ЛЕНТОЧНЫЙ ХОМУТ (8.00") TIE STRAP (8.00 Inches) |
AR | |
| 13 | 774572 |
РУКАВ (Общая длина 48.00") (Cut to 15.00 Inch Length) HOSE (48.00 Inches Bulk) (Cut to 15.00 Inch Length) |
1 | |
| 14 | 13791 |
ЗАЖИМ (15.7) CLAMP (15.7) |
3 | superseded |
| 14 | 856880 |
ЗАЖИМ Шланг (15.3) CLAMP Hose (15.3) |
2 | superseded |
| 2 | 840437 |
ЗАЖИМ CLIP |
1 | discontinued |
| 3 | 855896T |
ФИЛЬТР FILTER |
1 | discontinued |
| 4 | 830756109 |
РУКАВ (Общая длина 57.00") (Cut to 3.50 Inch Length) HOSE (57.00 Inches Bulk) (Cut to 3.50 Inch Length) |
1 | superseded |
| 5 | 840436 |
ЗАЖИМ CLIP |
1 | discontinued |
| 6 | 840435 |
РУКАВ HOSE |
1 | discontinued |
| 7 | 826544A1 |
КОМПЛЕКТ ТРУБОПРОВОДА TUBING KIT |
1 | discontinued |
| 8 | 8568172 |
РУКАВ HOSE |
1 | superseded |
| 9 | 8583253 |
ЗАЖИМ CLAMP |
1 | discontinued |
