ANCHOR BRACKET (NON SEAPRO/MARATHON) (S/N-0G303045 & BELOW)
Parts (37)
| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 814281A2 |
ПЕРЕКЛЮЧАТЕЛЬ SWITCH |
1 | superseded |
| 10 | 824014 |
ПРУЖИНА SPRING |
1 | discontinued |
| 11 | 8240111 |
НАПРАВЛЯЮЩАЯ Ролик GUIDE Roller |
1 | discontinued |
| 12 | 816207 |
СОЕДИНИТЕЛЬ Дроссельная заслонка USE WITH WMH-19 SERIES CARBURETORS LINK Throttle USE WITH WMH-19 SERIES CARBURETORS |
1 | superseded |
| 13 | 18181 |
СОЕДИНИТЕЛЬ (STUB SHAFT) USE WITH WMH-19 SERIES CARBURETORS LINK (STUB SHAFT) USE WITH WMH-19 SERIES CARBURETORS |
3 | discontinued |
| 14 | 825204A1 |
КОМПЛЕКТ СОЕДИНЕНИЯ Дроссельная заслонка USE WITH WMH-46/47 SERIES CARBURETORS LINK KIT Throttle USE WITH WMH-46/47 SERIES CARBURETORS |
1 | discontinued |
| 15 | 18181 |
СОЕДИНИТЕЛЬ (STUB SHAFT) USE WITH WMH-46/47 SERIES CARBURETORS LINK (STUB SHAFT) USE WITH WMH-46/47 SERIES CARBURETORS |
1 | discontinued |
| 16 | 181811 |
СОЕДИНИТЕЛЬ (BALL SHAFT) USE WITH WMH-46/47 SERIES CARBURETORS LINK (BALL SHAFT) USE WITH WMH-46/47 SERIES CARBURETORS |
2 | discontinued |
| 17 | 18178 |
РОЛИК ROLLER |
1 | |
| 18 | 87926 |
ВИНТ (№10-32 x 0.500) SCREW (#10-32 x .500) |
3 | discontinued |
| 19 | 89302 |
ШАЙБА (0.203 x 0.406 x 0.040) WASHER (.203 x .406 x .040) |
3 | |
| 2 | 82470620 |
ВИНТ (M3.5 x 20) SCREW (M3.5 x 20) |
2 | |
| 20 | 69432 |
СТОПОРНАЯ ШАЙБА Внешний (№10) LOCKWASHER External (#10) |
3 | |
| 21 | 1938523 |
СОЕДИНИТЕЛЬ LINK |
1 | discontinued |
| 22 | 932481 |
ВТУЛКА BUSHING |
3 | superseded |
| 23 | 429841 |
ШПИЛЬКА STUD |
1 | discontinued |
| 24 | 8183942 |
КУЛАЧОК Дроссельная заслонка CAM Throttle |
1 | discontinued |
| 25 | 69056 |
ШАЙБА (0.255 x 0.620 x 0.030), нержавеющая сталь WASHER (.255 x .620 x .030) Stainless Steel |
1 | |
| 26 | 8268336 |
ГАЙКА (M6) NUT (M6) |
1 | superseded |
| 27 | 818395 |
СОЕДИНИТЕЛЬ Дроссельная заслонка LINK Throttle |
1 | discontinued |
| 28 | 821113 |
ВТУЛКА BUSHING |
1 | |
| 29 | 40124 |
ВИНТ (M6 x 55) SCREW (M6 x 55) |
2 | |
| 3 | 8240102 |
КРОНШТЕЙН BRACKET |
1 | superseded |
| 30 | 400212 |
ГАЙКА (M6), нержавеющая сталь NUT (M6) Stainless Steel |
2 | |
| 31 | 42942 |
ПРОБКА CAP |
2 | |
| 32 | 8252681 |
РЫЧАГ Управление газом LEVER Throttle Control |
1 | superseded |
| 33 | 36042 |
ШАЙБА WASHER |
1 | |
| 34 | 81893435 |
ВИНТ (M8 x 35) SCREW (M8 x 35) |
1 | |
| 35 | 42927 |
ВСТАВКА INSERT |
1 | |
| 36 | 35459 |
ШАЙБА WASHER |
1 | |
| 37 | 8268336 |
ГАЙКА (M6) NUT (M6) |
1 | superseded |
| 4 | 42975 |
ХОДОВОЙ ВИНТ DRIVE SCREW |
2 | |
| 5 | 824016 |
ЗАЩЕЛКА LATCH |
1 | |
| 6 | 824015 |
КОЛПАЧОК Держатель бобины CUP Barrel Retainer |
2 | |
| 7 | 82155025 |
ВИНТ (M8 x 25 мм), нержавеющая сталь SCREW (M8 x 25 MM) Stainless Steel |
3 | |
| 8 | 824013 |
ВТУЛКА BUSHING |
1 | |
| 9 | 812707 |
ВТУЛКА BUSHING |
2 |
