| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8534A1 |
TOP COWL ASSEMBLY
|
1 |
disc.
|
| 10 |
9912846 |
TUBING (12" AND 3-1/4")
|
3 |
superseded
|
| 11 |
68424 |
CLAMP FUEL LINE ATTACHING
|
5 |
disc.
|
| 12 |
7568 |
CARBURETOR
|
1 |
disc.
|
| 13 |
70417 |
GASKET CARBURETOR
|
3 |
disc.
|
| 14 |
37998 |
WASHER CARBURETOR STUD
|
2 |
|
| 15 |
34688 |
NUT CARBURETOR STUD
|
2 |
superseded
|
| 16 |
88223 |
FOLLOWER Cam
|
1 |
disc.
|
| 17 |
4002027 |
NUT CAM FOLLOWER TO CARBURETOR
|
2 |
disc.
|
| 18 |
98601 |
BOX Sound
|
1 |
disc.
|
| 19 |
38627 |
SCREW (5/8 Inch) SOUND BOX
|
1 |
superseded
|
| 2 |
98807 |
GASKET TOP COWL
|
1 |
disc.
|
| 20 |
20346 |
WASHER SOUND BOX SCREW
|
2 |
superseded
|
| 21 |
89398 |
VALVE FUEL SHUT-OFF
|
1 |
disc.
|
| 22 |
76934 |
FILTER Fuel
|
1 |
|
| 23 |
97417 |
BRACKET FUEL TANK - REAR
|
1 |
disc.
|
| 24 |
90565 |
SCREW (.250-20 x .310) FUEL TANK CLAMP
|
1 |
disc.
|
| 25 |
26825 |
WASHER (.328 x .750 x .06) FUEL TANK SCREW
|
1 |
|
| 26 |
90501 |
BRACKET FUEL TANK - FRONT
|
1 |
disc.
|
| 27 |
90396 |
BUMPER FUEL TANK
|
2 |
disc.
|
| 28 |
90497 |
CLAMP FUEL TANK ATTACHING
|
1 |
disc.
|
| 29 |
714933 |
MOLDING TRIM - FUEL TANK CLAMP
|
1 |
disc.
|
| 3 |
8082 |
TANK Fuel
|
1 |
disc.
|
| 4 |
98808 |
GASKET FUEL TANK
|
1 |
disc.
|
| 5 |
41660A2 |
CAP ASSEMBLY Fuel
|
1 |
disc.
|
| 6 |
42573 |
O-RING FUEL CAP
|
1 |
disc.
|
| 7 |
76630 |
SCREW (.250-20 x 1.00) FUEL TANK TO POWERHEAD
|
2 |
superseded
|
| 8 |
20346 |
WASHER FUEL TANK SCREW
|
5 |
superseded
|
| 9 |
29031 |
NUT (1/4-20) FUEL TANK SCREW
|
2 |
disc.
|
