| # | Part Number | Description | Qty | Status |
|---|
| - |
813859A95 |
GASKET SET
|
1 |
|
| - |
809430T95 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
18789F1 |
CYLINDER HEAD
|
2 |
|
| 10 |
83075780 |
TUBING (28.00 Inches Bulk) (2-1/2 IN.)
|
1 |
superseded
|
| 11 |
7765378 |
TUBING (25.00 Inches) (10-1/2 IN.)
|
1 |
superseded
|
| 12 |
7765378 |
TUBING (25.00 Inches) (14-1/2 IN.)
|
1 |
superseded
|
| 13 |
83075780 |
TUBING (28.00 Inches Bulk) (7-1/2 IN.)
|
2 |
superseded
|
| 14 |
90824 |
TEE
|
1 |
superseded
|
| 15 |
816311 |
TIE STRAP (8.00 Inches)
|
AR |
superseded
|
| 16 |
63779 |
PIN Dowel (.250 x .625)
|
4 |
|
| 17 |
137151 |
RETAINER
|
2 |
|
| 18 |
98257 |
SCREW (.312-18 x .500)
|
2 |
|
| 19 |
28668 |
SCREW (.250-20 x .875) Stainless Steel
|
12 |
|
| 2 |
8146581 |
GASKET
|
2 |
|
| 20 |
167371 |
GASKET
|
1 |
|
| 21 |
12124A3 |
PLATE ASSEMBLY
|
1 |
disc.
|
| 22 |
903911 |
CLAMP Reed
|
12 |
|
| 23 |
813859 |
GASKET
|
1 |
superseded
|
| 24 |
876922 |
BLOCK
|
6 |
superseded
|
| 25 |
815242A3 |
REED KIT
|
6 |
|
| 26 |
28668 |
SCREW (.250-20 x .875) Stainless Steel
|
8 |
|
| 27 |
823588 |
SCREW (#8-32 x .250)
|
84 |
|
| 28 |
97465 |
SENDER Temperature (STARBOARD)
|
1 |
|
| 29 |
13536A6 |
SENSOR ASSEMBLY Temperature (PORT)
|
1 |
|
| 3 |
98534 |
SCREW (.375-16 x 2.30)
|
24 |
disc.
|
| 30 |
55098 |
J CLIP
|
1 |
superseded
|
| 4 |
815914 |
T-FITTING
|
1 |
|
| 5 |
75692 |
THERMOSTAT
|
2 |
|
| 6 |
62386 |
GASKET
|
2 |
superseded
|
| 7 |
90390A1 |
COVER KIT
|
2 |
|
| 8 |
35386 |
SCREW (.312-18 x 1.00)
|
4 |
|
| 9 |
136071 |
ELBOW WATER HOSES
|
2 |
|
