| # | Part Number | Description | Qty | Status |
|---|
| - |
813859A95 |
GASKET SET
|
1 |
|
| - |
809430T95 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
9763T62 |
CYLINDER BLOCK
|
1 |
superseded
|
| 10 |
828214 |
SCREW (.312-18 x 2.00) Hex Flange
|
2 |
|
| 11 |
99448 |
BUSHING
|
1 |
|
| 12 |
88807A20 |
CABLE ASSEMBLY
|
1 |
|
| 13 |
66717 |
SCREW (.375-16 x 3.250)
|
8 |
|
| 13 |
74824 |
SCREW (.312-18 x 1.250)
|
6 |
|
| 14 |
9642A1 |
END CAP ASSEMBLY Upper
|
1 |
superseded
|
| 15 |
54029 |
O-RING (2.800 x .103)
|
1 |
|
| 16 |
16756A4 |
BEARING KIT
|
1 |
|
| 17 |
41953 |
SEAL
|
1 |
|
| 18 |
69034 |
SCREW AND LOCKWASHER (.312-18 x 1.00)
|
4 |
superseded
|
| 19 |
814634 |
CLAMP
|
1 |
|
| 2 |
847530 |
STUD (.375-16/.375-24 x 2.040)
|
6 |
superseded
|
| 20 |
15094 |
STUD (.190-32 x 1.870)
|
1 |
disc.
|
| 21 |
67269 |
SPACER
|
1 |
|
| 22 |
49221 |
WASHER (.187 x .500 x .062) Neoprene
|
3 |
superseded
|
| 23 |
816874 |
WING NUT (#10-32)
|
3 |
|
| 24 |
87076A10 |
IDLE SPEED CONTROL
|
1 |
disc.
|
| 25 |
69020 |
SCREW (#10-32 x .875)
|
3 |
superseded
|
| 26 |
38833 |
WASHER
|
3 |
|
| 27 |
42248 |
BRACKET
|
1 |
superseded
|
| 28 |
49668 |
SCREW (.250-20 x .750)
|
2 |
|
| 29 |
15093 |
STUD (#10-32 x 1.00)
|
2 |
superseded
|
| 3 |
670653 |
STUD (.375 x 5.620)
|
2 |
superseded
|
| 3 |
847532 |
STUD (.375-16/.375-24 x 5.750)
|
2/4 |
superseded
|
| 3 |
784384 |
STUD (.375 x 6.870)
|
2 |
superseded
|
| 30 |
64022 |
SCREW (.250-20 x 2.125)
|
1 |
|
| 31 |
64015 |
NUT (.250-20)
|
1 |
|
| 32 |
26852 |
CAP Nylon
|
1 |
|
| 33 |
7809A1 |
END CAP ASSEMBLY
|
1 |
superseded
|
| 34 |
62700 |
O-RING (3.237 x .103)
|
1 |
|
| 35 |
41953 |
SEAL
|
2 |
|
| 36 |
28636 |
SCREW (.250-20 x .750)
|
4 |
|
| 37 |
26992 |
LOCKWASHER (.250) Stainless Steel
|
4 |
|
| 4 |
43044 |
PIN Dowel - Without Hole (.375 x .625)
|
2 |
|
| 5 |
67296 |
PIN (BEARING RACE)
|
2 |
superseded
|
| 6 |
11338 |
GASKET
|
2 |
|
| 7 |
42249 |
COVER (UPPER)
|
1 |
superseded
|
| 8 |
828213 |
SCREW (.312-18 x 1.500) Hex Flange
|
2 |
|
| 9 |
76867 |
COVER (LOWER)
|
1 |
|
