| # | Part Number | Description | Qty | Status |
|---|
| - |
813859A95 |
GASKET SET
|
1 |
|
| - |
809430T95 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
14360A53 |
PUMP ASSEMBLY Fuel
|
1 |
superseded
|
| 10 |
NSS |
NOT SOLD SEPARATE Retainer
|
2 |
|
| 11 |
NSS |
NOT SOLD SEPARATE Spring
|
1 |
|
| 12 |
NSS |
NOT SOLD SEPARATE Cap
|
1 |
|
| 13 |
987691 |
GASKET Base
|
1 |
superseded
|
| 14 |
144303 |
BASE
|
1 |
|
| 15 |
987752 |
PLATE
|
1 |
|
| 16 |
996641 |
ELBOW
|
1 |
superseded
|
| 17 |
29111 |
CONNECTOR
|
1 |
superseded
|
| 18 |
43335 |
CONNECTOR 90 Degree (.125-27) Nylon
|
1 |
superseded
|
| 19 |
82104540 |
SCREW (M5 x 40)
|
2 |
|
| 2 |
42990A10 |
DIAPHAGM KIT
|
1 |
superseded
|
| 20 |
16452 |
SCREW (#12-24 x 2.00)
|
2 |
|
| 21 |
9912878 |
HOSE (.187) (26.00 Inches Bulk) (7-1/2 IN.)
|
1 |
|
| 22 |
99751 |
FITTING (.0625-27) Brass
|
1 |
superseded
|
| 23 |
83075780 |
TUBING (28.00 Inches Bulk) (13-1/2 IN.)
|
1 |
superseded
|
| 24 |
816311 |
TIE STRAP (8.00 Inches)
|
AR |
superseded
|
| 25 |
822769 |
CONNECTOR
|
1 |
|
| 26 |
1350385 |
TUBING (33.00 Inches Bulk) (15-1/2 IN.)(19 IN.)
|
2 |
|
| 27 |
18458A4 |
FILTER KIT
|
1 |
superseded
|
| 28 |
828586 |
PROBE
|
1 |
superseded
|
| 29 |
13170A3 |
BASE
|
1 |
disc.
|
| 3 |
NSS |
NOT SOLD SEPARATE Check Valve-Rubber
|
2 |
|
| 30 |
897712 |
CONNECTOR (.250-18) (STRAIGHT)
|
1 |
superseded
|
| 31 |
136071 |
ELBOW
|
1 |
|
| 32 |
45561 |
SCREW (.250-20 x 1.12)
|
2 |
superseded
|
| 4 |
NSS |
NOT SOLD SEPARATE Gasket-Boost
|
1 |
|
| 5 |
NSS |
NOT SOLD SEPARATE Diaphragm
|
2 |
|
| 6 |
NSS |
NOT SOLD SEPARATE Gasket-Pulse
|
1 |
|
| 7 |
NSS |
NOT SOLD SEPARATE Spring
|
1 |
|
| 8 |
NSS |
NOT SOLD SEPARATE Cap
|
1 |
|
| 9 |
NSS |
NOT SOLD SEPARATE Check Valve
|
2 |
|
