| # | Part Number | Description | Qty | Status |
|---|
| - |
814195A97 |
GASKET SET
|
1 |
disc.
|
| - |
809973A97 |
POWERHEAD ASSEMBLY
|
1 |
disc.
|
| 1 |
830051A1 |
FLYWHEEL COVER
|
1 |
disc.
|
| 10 |
834828 |
GASKET
|
1 |
disc.
|
| 11 |
8283711 |
BACKING PLATE
|
1 |
disc.
|
| 12 |
8141951 |
GASKET
|
1 |
|
| 13 |
82130025 |
SCREW (M6 x 25) (M6 X 25)
|
12 |
|
| 14 |
828623 |
REED BLOCK (1-PIECE)
|
6 |
superseded
|
| 15 |
4007425 |
SCREW (M6 X 1 X 25)
|
12 |
disc.
|
| 16 |
8281241 |
PUMP Oil
|
1 |
superseded
|
| 17 |
828432 |
GASKET
|
1 |
disc.
|
| 18 |
81893435 |
SCREW (M8 x 35) (M8 X 35)
|
2 |
|
| 18 |
12516F2 |
SCREW (M8 x 133.35) Upper Mount (M8 X 133.35)
|
1 |
superseded
|
| 19 |
4002317 |
WASHER (8.90 X 17.0 X 1.9SS)
|
1 |
|
| 2 |
834921 |
GROMMET
|
3 |
disc.
|
| 20 |
853565 |
BRACKET Oil Pump
|
1 |
disc.
|
| 21 |
81893445 |
SCREW (M8 X 45)
|
2 |
disc.
|
| 22 |
99498 |
FITTING
|
1 |
|
| 23 |
816311 |
TIE STRAP (8.00 Inches)
|
1 |
superseded
|
| 24 |
82381451 |
TUBING (23 IN.)
|
1 |
superseded
|
| 25 |
76843 |
FITTING
|
1 |
superseded
|
| 26 |
99130122 |
TUBING (20.00 Feet Bulk) (31 IN.)
|
1 |
superseded
|
| 3 |
86361 |
GROMMET
|
1 |
|
| 4 |
834925 |
RESTRICTOR (8MM)
|
1 |
disc.
|
| 5 |
834922 |
FILTER AIR
|
1 |
disc.
|
| 6 |
49542 |
CLAMP
|
2 |
disc.
|
| 7 |
82130012 |
SCREW (M6 x 12) (M6 X 12)
|
2 |
|
| 8 |
825815 |
GASKET
|
3 |
|
| 9 |
8283721 |
ADAPTER PLATE
|
1 |
superseded
|
