| # | Part Number | Description | Qty | Status |
|---|
| - |
809839A94 |
POWERHEAD ASSEMBLY (150)
|
1 |
superseded
|
| - |
808603A94 |
POWERHEAD ASSEMBLY (200)
|
1 |
superseded
|
| 1 |
12430A4 |
SENSOR ASSEMBLY
|
1 |
|
| 10 |
99802 |
TUBE
|
1 |
|
| 11 |
432781 |
CHECK VALVE (CRANKCASE)
|
1 |
superseded
|
| 12 |
99439 |
HOSE (114.00 Inches)
|
1 |
|
| 13 |
994436 |
RESERVOIR
|
1 |
|
| 14 |
43300A9 |
CAP ASSEMBLY
|
1 |
|
| 15 |
99022A1 |
FLOAT ASSEMBLY
|
1 |
superseded
|
| 16 |
99265 |
PUSH NUT
|
1 |
|
| 17 |
43307 |
GASKET
|
1 |
superseded
|
| 18 |
830756109 |
HOSE (57.00 Inches Bulk) (6 IN.)
|
1 |
superseded
|
| 19 |
424254 |
FITTING
|
1 |
superseded
|
| 2 |
8128321 |
SCREW (#10-16 x .600)
|
1 |
superseded
|
| 20 |
69020 |
SCREW (#10-32 x .875)
|
3 |
superseded
|
| 21 |
42118 |
WASHER
|
6 |
|
| 22 |
42117 |
GROMMET
|
3 |
|
| 23 |
42116 |
BUSHING
|
3 |
|
| 24 |
816311 |
TIE STRAP (8.00 Inches)
|
AR |
superseded
|
| 25 |
1938512 |
LINK ASSEMBLY
|
1 |
|
| 26 |
82381335 |
TUBING (15.00 Inches Bulk) (7 IN.)
|
1 |
|
| 27 |
816311 |
TIE STRAP (8.00 Inches)
|
2 |
superseded
|
| 28 |
815699T |
PUMP ASSEMBLY Oil
|
1 |
|
| 29 |
11379 |
O-RING
|
1 |
|
| 3 |
12335A1 |
BRACKET KIT
|
1 |
|
| 30 |
32228 |
SCREW (#10-32 x .625)
|
1 |
|
| 30 |
41507 |
SCREW (#10-32 x 1.120)
|
1 |
|
| 31 |
41429A2 |
BEARING ASSEMBLY
|
1 |
|
| 32 |
14563 |
GEAR Driven
|
1 |
|
| 33 |
82381455 |
TUBING (25.00 Inches Bulk) (4-3/4 IN.)
|
1 |
|
| 34 |
816311 |
TIE STRAP (8.00 Inches)
|
2 |
superseded
|
| 4 |
12323A1 |
CORD/HOOK KIT
|
1 |
|
| 5 |
87421 |
TANK
|
1 |
|
| 6 |
43298A2 |
CAP ASSEMBLY
|
1 |
|
| 7 |
11332 |
O-RING (2.225 x .210)
|
1 |
|
| 8 |
816190A3 |
HOUSING ASSEMBLY Adapter
|
1 |
superseded
|
| 9 |
11332 |
O-RING (2.225 x .210)
|
1 |
|
