| # | Part Number | Description | Qty | Status |
|---|
| - |
814247T3 |
GEAR HOUSING ASSEMBLY Complete BLACK
|
1 |
disc.
|
| - |
814247T4 |
GEAR HOUSING ASSEMBLY Complete GRAY
|
1 |
disc.
|
| - |
96148A5 |
REPAIR KIT Water Pump
|
1 |
superseded
|
| - |
89238A2 |
SEAL KIT
|
1 |
|
| 1 |
814247T1 |
GEAR HOUSING ASSEMBLY Basic-Black
|
1 |
disc.
|
| 1 |
814247A2 |
GEAR HOUSING ASSEMBLY Basic - Gray
|
1 |
superseded
|
| 10 |
NSS |
NOT SOLD SEPARATE Pinion Gear-Part of 43-16279A2
|
1 |
|
| 11 |
35921 |
NUT (.625-18)
|
1 |
|
| 12 |
67892A1 |
FITTING KIT Magnetic, Plug Fill/Drain
|
1 |
superseded
|
| 13 |
79953A2 |
SCREW KIT (.375-16 x .250)
|
1 |
superseded
|
| 14 |
19183 |
WASHER Fiber
|
2 |
superseded
|
| 15 |
8152641 |
SHIFT SHAFT
|
1 |
disc.
|
| 16 |
77631A2 |
BUSHING ASSEMBLY
|
1 |
|
| 17 |
25439 |
O-RING (.862 x .103)
|
1 |
|
| 18 |
8164641 |
SEAL Oil
|
1 |
superseded
|
| 19 |
77674 |
WASHER (.35 x .75 x .12)
|
1 |
|
| 2 |
85822A10 |
CONNECTOR ASSEMBLY
|
1 |
|
| 20 |
815168 |
DRIVESHAFT
|
1 |
disc.
|
| 21 |
42637A1 |
SHIM SET
|
AR |
disc.
|
| 22 |
36387A1 |
BEARING ASSEMBLY Roller/Cup
|
1 |
superseded
|
| 23 |
824519 |
RETAINER
|
1 |
superseded
|
| 24 |
42579A3 |
BASE ASSEMBLY Water Pump
|
1 |
superseded
|
| 25 |
426311 |
GASKET
|
1 |
superseded
|
| 26 |
90011 |
O-RING (2.175 x .175)
|
1 |
superseded
|
| 27 |
89238 |
SEAL Oil
|
1 |
|
| 28 |
16977 |
SEAL Oil
|
1 |
|
| 29 |
856081 |
GASKET
|
1 |
superseded
|
| 3 |
43044 |
PIN Dowel - Without Hole (.375 x .625)
|
2 |
|
| 30 |
856091 |
GASKET
|
1 |
superseded
|
| 31 |
32435 |
FACE PLATE
|
1 |
superseded
|
| 32 |
96148A1 |
BODY ASSEMBLY Water Pump
|
1 |
superseded
|
| 33 |
48752 |
INSERT
|
1 |
superseded
|
| 34 |
38970 |
SEAL
|
1 |
|
| 35 |
899843 |
IMPELLER
|
1 |
superseded
|
| 36 |
56654 |
KEY
|
1 |
superseded
|
| 37 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
2 |
superseded
|
| 38 |
13438 |
NUT (.250-28)
|
2 |
superseded
|
| 39 |
36001 |
WASHER
|
1 |
|
| 4 |
786382 |
STUD (.437-14/.437-20 x 3.120)
|
1 |
|
| 40 |
13436 |
NUT
|
1 |
|
| 41 |
96411 |
SCREW (#14-8 x 2.25)
|
1 |
superseded
|
| 42 |
29804 |
SLEEVE
|
1 |
superseded
|
| 5 |
579203 |
STUD (.437-14/.437-20 x 2.060)
|
2 |
superseded
|
| 6 |
562972 |
STUD (.312-18/.324-24 x 3.380)
|
1 |
superseded
|
| 7 |
30667 |
STUD (.250-20/.250-28 x 3.125)
|
2 |
superseded
|
| 8 |
35934A1 |
BEARING ASSEMBLY Roller
|
1 |
|
| 9 |
67891 |
FILLER BLOCK
|
1 |
superseded
|
