| # | Part Number | Description | Qty | Status |
|---|
| 1 |
818810A8 |
SWIVEL BRACKET ASSEMBLY BLACK
|
1 |
superseded
|
| 1 |
818810A7 |
SWIVEL BRACKET ASSEMBLY GRAY
|
1 |
disc.
|
| 10 |
48171 |
O-RING (.364. x .070)
|
2 |
|
| 11 |
85030A2 |
LEVER ASSEMBLY Tilt Lock PORT-BLACK
|
1 |
disc.
|
| 11 |
85030A3 |
LEVER ASSEMBLY Tilt Lock PORT-GRAY
|
1 |
disc.
|
| 11 |
85028A2 |
LEVER ASSEMBLY Tilt Lock STARBOARD-BLACK
|
1 |
disc.
|
| 11 |
85028A3 |
LEVER ASSEMBLY Tilt Lock STARBOARD-GRAY
|
1 |
disc.
|
| 12 |
86600 |
BUSHING
|
1 |
disc.
|
| 13 |
85367 |
SPRING
|
1 |
disc.
|
| 14 |
41052 |
PLUNGER
|
1 |
disc.
|
| 15 |
88876 |
STUD
|
1 |
disc.
|
| 16 |
86603 |
KNOB
|
1 |
disc.
|
| 17 |
864751 |
COUPLING
|
1 |
|
| 18 |
69745 |
PIN Roll
|
2 |
|
| 19 |
88049 |
SPRING
|
1 |
|
| 2 |
847729 |
SEAL Oil
|
2 |
|
| 20 |
93861 |
COTTER PIN
|
1 |
disc.
|
| 21 |
78854 |
WAVE WASHER
|
1 |
|
| 22 |
86580F4 |
YOKE Bottom BLACK
|
1 |
disc.
|
| 22 |
86580F5 |
YOKE Bottom GRAY
|
1 |
disc.
|
| 23 |
848125 |
RING Retaining - Spiral Lock
|
2 |
|
| 24 |
67706A59 |
SWIVEL PIN ASSEMBLY Steering Arm BLACK
|
1 |
superseded
|
| 24 |
67706A60 |
SWIVEL PIN ASSEMBLY Steering Arm GRAY
|
1 |
superseded
|
| 25 |
92876A1 |
LINK ASSEMBLY Steering
|
1 |
superseded
|
| 26 |
849838 |
SCREW (.375-24 x 1.250)
|
1 |
|
| 27 |
34863 |
NUT (.375-24)
|
2 |
superseded
|
| 28 |
37828 |
WASHER (.390 x .625 x .062) Stainless Steel
|
2 |
|
| 29 |
849581 |
SCREW (7-3/4 IN.)
|
2 |
superseded
|
| 3 |
847726 |
BEARING
|
2 |
|
| 30 |
816056 |
WASHER
|
4 |
|
| 31 |
8495861 |
MOUNT
|
2 |
superseded
|
| 32 |
844766 |
NUT (.500-13)
|
2 |
|
| 4 |
74036 |
FITTING Grease
|
4 |
superseded
|
| 5 |
847728 |
BEARING
|
2 |
|
| 6 |
82203524 |
BEARING (1-1/2 IN.)
|
2 |
|
| 7 |
82203540 |
BEARING (2-1/2 IN.)
|
2 |
|
| 8 |
85023 |
SEAL Oil
|
2 |
|
| 9 |
87161 |
WASHER
|
2 |
|
