| # | Part Number | Description | Qty | Status |
|---|
| - |
823142A98 |
GASKET SET Engine
|
1 |
disc.
|
| - |
809839A94 |
POWERHEAD ASSEMBLY (150)
|
1 |
superseded
|
| - |
808603A94 |
POWERHEAD ASSEMBLY (200)
|
1 |
superseded
|
| 1 |
18488F1 |
CYLINDER HEAD
|
2 |
superseded
|
| 10 |
83075780 |
TUBING (28.00 Inches Bulk) (2-1/2 IN.)(7-1/2 IN.)(7-1/2 IN.)(10-1/2 IN.)(14-1/2 IN.)
|
5 |
superseded
|
| 11 |
90824 |
TEE
|
1 |
superseded
|
| 12 |
816311 |
TIE STRAP (8.00 Inches)
|
AR |
superseded
|
| 13 |
63779 |
PIN Dowel (.250 x .625)
|
4 |
|
| 14 |
137151 |
RETAINER
|
2 |
|
| 15 |
98257 |
SCREW (.312-18 x .500)
|
2 |
|
| 16 |
55715 |
SCREW (.250-20 x .880)
|
6 |
|
| 16 |
90197 |
SCREW (.250-20 x 1.125)
|
6 |
disc.
|
| 17 |
167371 |
GASKET
|
1 |
|
| 18 |
17735A2 |
ADAPTER PLATE ASSEMBLY
|
1 |
disc.
|
| 19 |
146972 |
GASKET
|
1 |
|
| 2 |
8228441 |
GASKET
|
2 |
superseded
|
| 20 |
11645A4 |
REED BLOCK
|
6 |
disc.
|
| 21 |
14594A3 |
REED ASSEMBLY
|
6 |
superseded
|
| 22 |
849038 |
SCREW (M3 x 5)
|
48 |
|
| 23 |
28668 |
SCREW (.250-20 x .875) Stainless Steel
|
8 |
|
| 24 |
97465 |
SENDER Temperature STARBOARD
|
1 |
|
| 25 |
13536A6 |
SENSOR ASSEMBLY Temperature PORT
|
1 |
|
| 26 |
55098 |
J CLIP
|
1 |
superseded
|
| 3 |
98534 |
SCREW (.375-16 x 2.30)
|
24 |
disc.
|
| 4 |
815914 |
T-FITTING
|
1 |
|
| 5 |
75692 |
THERMOSTAT
|
2 |
|
| 6 |
62386 |
GASKET
|
2 |
superseded
|
| 7 |
90390A1 |
COVER KIT
|
2 |
|
| 8 |
35386 |
SCREW (.312-18 x 1.00)
|
4 |
|
| 9 |
136071 |
ELBOW WATER HOSES
|
2 |
|
