| # | Part Number | Description | Qty | Status |
|---|
| 1 |
849761 |
PLATE
|
1 |
superseded
|
| 10 |
73286 |
SCREW (.250-20 x .500) Stainless Steel
|
2 |
|
| 11 |
69028 |
SCREW (.250-28 x .750) Stainless Steel
|
2 |
|
| 12 |
35462 |
WASHER (.2656 x .625 x .0625) Stainless Steel
|
2 |
|
| 13 |
55098 |
J CLIP
|
1 |
superseded
|
| 14 |
35280 |
WASHER (.255 x .620 x .030) Stainless Steel
|
2 |
|
| 15 |
35045 |
NUT (.250-28)
|
2 |
superseded
|
| 16 |
826802A4 |
HARNESS ASSEMBLY
|
1 |
|
| 2 |
828151A1 |
RELAY ASSEMBLY
|
2 |
superseded
|
| 3 |
818967 |
GROMMET
|
2 |
|
| 4 |
818968 |
BUSHING
|
2 |
superseded
|
| 5 |
828102 |
BRACKET
|
2 |
superseded
|
| 6 |
45561 |
SCREW (.250-20 x 1.12)
|
2 |
superseded
|
| 7 |
35950 |
WASHER (.273 x .437 x .031) Stainless Steel
|
2 |
|
| 8 |
814101 |
NUT (.250-20) Stainless Steel
|
2 |
superseded
|
| 9 |
26992 |
LOCKWASHER (.250) Stainless Steel
|
2 |
|
