| # | Part Number | Description | Qty | Status |
|---|
| - |
848700A7 |
POWERHEAD ASSEMBLY
|
1 |
disc.
|
| 1 |
9811A56 |
CYLINDER BLOCK
|
1 |
disc.
|
| 10 |
82446180 |
SCREW (M10 x 80)
|
8 |
|
| 11 |
67296 |
PIN
|
3 |
superseded
|
| 12 |
850309 |
PLUG
|
6 |
superseded
|
| 13 |
426585 |
CHECK VALVE
|
2 |
|
| 14 |
8159234 |
CHECK VALVE
|
2 |
|
| 15 |
99130122 |
TUBING (20.00 Feet Bulk) (Cut to 22-1/2 IN.)
|
1 |
superseded
|
| 16 |
99130122 |
TUBING (20.00 Feet Bulk) (Cut to 3-3/4 IN.)
|
1 |
superseded
|
| 17 |
77863A1 |
FITTING ASSEMBLY
|
1 |
disc.
|
| 18 |
8217621 |
TIMING POINTER
|
1 |
disc.
|
| 19 |
82130012 |
SCREW (M6 x 12)
|
1 |
|
| 2 |
903509 |
STUD (M10 x 1.5 x 64)
|
4 |
|
| 20 |
816311T |
TIE STRAP (8.00 Inches)
|
AR |
|
| 21 |
826544A1 |
TUBING KIT
|
1 |
disc.
|
| 22 |
687271 |
FITTING (.250-18) 90 Degree - Brass
|
1 |
|
| 23 |
856774 |
WASHER (.406 x .750 x .105) Stainless Steel
|
10 |
superseded
|
| 24 |
4013610 |
NUT (M10) Stainless Steel
|
10 |
|
| 25 |
8256751 |
BRACKET
|
1 |
disc.
|
| 26 |
82130012 |
SCREW (M6 x 12)
|
1 |
|
| 27 |
8211051 |
BRACKET Alternator
|
1 |
|
| 28 |
81893450 |
SCREW (M8 x 50)
|
2 |
|
| 29 |
8212251 |
BRACKET
|
1 |
disc.
|
| 3 |
8154431 |
STUD (M10 x 1.5 x 155)
|
6 |
|
| 30 |
82130012 |
SCREW (M6 x 12)
|
2 |
|
| 31 |
822486 |
BRACKET Guide
|
1 |
disc.
|
| 32 |
821909 |
SENSOR
|
1 |
|
| 33 |
82104510 |
SCREW (M5 x 10)
|
1 |
|
| 34 |
818574 |
SEAL Cylinder Head
|
2 |
|
| 35 |
812851A16 |
CYLINDER HEAD
|
2 |
disc.
|
| 36 |
878453 |
SEAL [0T235000] & Up
|
6 |
|
| 36 |
818573 |
O-RING [0T234999] & Below
|
6 |
|
| 37 |
833072 |
THERMOSTAT 62° Celsius (143° Fahrenheit)
|
2 |
superseded
|
| 38 |
62386 |
GASKET Thermostat
|
2 |
superseded
|
| 39 |
19801A1 |
THERMOSTAT COVER
|
2 |
|
| 4 |
328022 |
PLUG Pipe (.125-27) Brass
|
1 |
|
| 40 |
8167811 |
ELBOW
|
2 |
|
| 41 |
77653101 |
HOSE (48.00 Inches Bulk) (Cut to 19 IN.) (PORT)
|
1 |
|
| 41 |
77653101 |
HOSE (48.00 Inches Bulk) (Cut to 20-1/2 IN.) (STARBOARD)
|
1 |
|
| 42 |
82446090 |
SCREW (M8 x 90)
|
4 |
|
| 43 |
859096 |
SCREW (M8 x 50)
|
36 |
superseded
|
| 44 |
13536A14 |
SENSOR ASSEMBLY Temperature
|
1 |
|
| 45 |
137151 |
RETAINER
|
1 |
|
| 46 |
81893414 |
SCREW (M8 x 14)
|
1 |
|
| 47 |
9787A4 |
END CAP ASSEMBLY
|
1 |
|
| 48 |
62700 |
O-RING (3.237 x .103)
|
1 |
|
| 49 |
8308981 |
SEAL
|
2 |
|
| 5 |
8248577 |
DEFLECTOR
|
4 |
|
| 50 |
82130020 |
SCREW (M6 x 20)
|
4 |
|
| 51 |
8261211 |
BRACKET
|
1 |
disc.
|
| 52 |
48408 |
SCREW (#10-16 x .500)
|
1 |
|
| 53 |
82130012 |
SCREW (M6 x 12)
|
2 |
|
| 54 |
8266241 |
CLAMP
|
1 |
|
| 6 |
8781051 |
CHECK VALVE
|
1 |
|
| 7 |
43044 |
PIN Dowel - Without Hole (.375 x .625)
|
1 |
|
| 8 |
8215832 |
PIN Special (1.5 Inches)
|
2 |
|
| 9 |
81893435 |
SCREW (M8 x 35)
|
14 |
|
