| # | Part Number | Description | Qty | Status |
|---|
| - |
825818A14 |
MANAGEMENT ASSEMBLY Fuel
|
1 |
disc.
|
| 1 |
8140111 |
BODY KIT
|
1 |
disc.
|
| 10 |
809079 |
GROMMET
|
3 |
superseded
|
| 11 |
809078 |
COLLAR
|
3 |
disc.
|
| 12 |
15445 |
FLOAT KIT
|
1 |
disc.
|
| 13 |
15446 |
VALVE KIT Float
|
1 |
|
| 14 |
8140101 |
COVER
|
1 |
disc.
|
| 15 |
809085 |
ELBOW KIT
|
1 |
disc.
|
| 16 |
8140761 |
SCREW KIT
|
1 |
disc.
|
| 17 |
809090 |
CONNECTION KIT Electrical
|
1 |
disc.
|
| 18 |
8276941 |
TUBING KIT
|
1 |
superseded
|
| 19 |
809087 |
ATTACHING KIT
|
1 |
disc.
|
| 2 |
809091 |
SCREW KIT
|
1 |
disc.
|
| 20 |
814012T1 |
REGULATOR KIT Fuel Pressure
|
1 |
disc.
|
| 21 |
809088T |
PUMP KIT Fuel
|
1 |
disc.
|
| 22 |
808504T1 |
STRAINER KIT
|
1 |
disc.
|
| 23 |
809089 |
FITTING KIT Fuel Pump
|
1 |
disc.
|
| 24 |
150291 |
O-RING KIT
|
1 |
|
| 25 |
8237515 |
NUT (M4)
|
1 |
|
| 26 |
400211 |
NUT (M5) Stainless Steel
|
1 |
|
| 27 |
26995 |
LOCKWASHER (#8) Stainless Steel
|
1 |
|
| 28 |
825762 |
SENSOR MAP
|
1 |
|
| 29 |
82130012 |
SCREW (M6 x 12)
|
2 |
|
| 3 |
809086 |
O-RING
|
1 |
|
| 30 |
804675A00 |
DECAL EPA Label Information (2000)
|
1 |
disc.
|
| 30 |
804675A01 |
DECAL EPA Label Information (2001)
|
1 |
disc.
|
| 30 |
804675A02 |
DECAL EPA Label Information (2002)
|
1 |
disc.
|
| 30 |
804675A03 |
DECAL EPA Label Information (2003)
|
1 |
disc.
|
| 31 |
NSS |
NOT SOLD SEPARATE DECAL, Caution (In Gear Idle)
|
1 |
|
| 32 |
881865 |
DECAL Caution-Start in Gear (Start In Gear)
|
1 |
|
| 4 |
424811 |
VALVE
|
1 |
|
| 5 |
809092 |
SCREW KIT Mounting
|
1 |
disc.
|
| 6 |
809061 |
BOLT
|
3 |
disc.
|
| 7 |
809080 |
LOCKWASHER
|
3 |
superseded
|
| 8 |
8090621 |
WASHER
|
3 |
|
| 9 |
8090622 |
WASHER
|
3 |
disc.
|
