| # | Part Number | Description | Qty | Status |
|---|
| 1 |
814277A49 |
TOP COWL ASSEMBLY Black
|
1 |
superseded
|
| 10 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
4 |
superseded
|
| 11 |
401366 |
NUT (M6) Stainless Steel
|
4 |
|
| 12 |
821249M2 |
BRACKET Front
|
1 |
superseded
|
| 13 |
815477 |
BUMPER Latch
|
1 |
|
| 14 |
8155381 |
PIN Roll
|
1 |
|
| 15 |
401366 |
NUT (M6) Stainless Steel
|
3 |
|
| 16 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
3 |
superseded
|
| 17 |
826639T |
COVER
|
1 |
|
| 18 |
47341A11 |
ROPE AND HANDLE KIT Manual Starting
|
1 |
|
| 19 |
804801A00 |
DECAL SET
|
1 |
disc.
|
| 2 |
821256T1 |
INLET Air - Black
|
1 |
superseded
|
| 3 |
82130016 |
SCREW (M6 x 16)
|
4 |
|
| 4 |
821250A1 |
SOUND BLANKET KIT
|
1 |
disc.
|
| 5 |
NSS |
NOT SOLD SEPARATE Sound Blanket (SIDE)
|
2 |
|
| 6 |
823865 |
CAP PLUG
|
2 |
|
| 7 |
821248 |
REAR LATCH HOOK
|
2 |
|
| 8 |
8237951 |
RING Retaining
|
3 |
|
| 9 |
815263 |
ROLLER
|
3 |
superseded
|
