| # | Part Number | Description | Qty | Status |
|---|
| 1 |
822769 |
CONNECTOR
|
1 |
|
| 10 |
4008820 |
SCREW (M6 x 20)
|
6 |
|
| 11 |
400256 |
LOCKWASHER (M6)
|
6 |
|
| 12 |
8268336 |
NUT (M6)
|
6 |
superseded
|
| 13 |
822528T |
SOLENOID VALVE
|
1 |
|
| 14 |
8224931 |
BRACKET
|
1 |
disc.
|
| 15 |
9912878 |
HOSE (.187) (26.00 Inches Bulk) (8-3/4 IN.)
|
2 |
|
| 16 |
9912878 |
HOSE (.187) (26.00 Inches Bulk) (6 IN.)
|
1 |
|
| 17 |
89694 |
KEY
|
1 |
|
| 18 |
821153 |
COUPLING
|
1 |
|
| 19 |
8212021 |
BRACKET Sensor
|
1 |
disc.
|
| 2 |
830757130 |
TUBING (.312) (70.00 Inches Bulk) (1-1/2 IN.)
|
1 |
superseded
|
| 20 |
821664 |
SENSOR Throttle Position (TPI)
|
1 |
disc.
|
| 21 |
4005685 |
SCREW (M4 x 10)
|
2 |
|
| 22 |
30164 |
WASHER (.192 x .375 x .0312) Stainless Steel
|
2 |
|
| 23 |
26995 |
LOCKWASHER (#8) Stainless Steel
|
2 |
|
| 24 |
82459612 |
OVERSLEEVE
|
2 |
disc.
|
| 25 |
56762 |
TIE STRAP (4.00 Inches)
|
3 |
|
| 26 |
830770 |
HOSE (OUTLET) [0G960500] & Up
|
1 |
disc.
|
| 27 |
830769 |
HOSE (INLET)(8-1/4IN.) [0G960500] & Up
|
1 |
disc.
|
| 28 |
826634T |
FILTER Fuel [0G960500] & Up
|
1 |
superseded
|
| 29 |
830756109 |
HOSE (57.00 Inches Bulk) (16 IN.) [0G960500] & Up
|
1 |
superseded
|
| 3 |
830757130 |
TUBING (.312) (70.00 Inches Bulk) (13-1/2 IN.)
|
1 |
superseded
|
| 30 |
826635 |
BRACKET [0G960500] & Up
|
1 |
disc.
|
| 31 |
82130012 |
SCREW (M6 x 12) [0G960500] & Up
|
4 |
|
| 32 |
67015 |
CLAMP [0G960500] & Up
|
1 |
disc.
|
| 33 |
82130012 |
SCREW (M6 x 12)
|
1 |
|
| 34 |
830757130 |
TUBING (.312) (70.00 Inches Bulk) (4 IN.) [0G960499] & Below
|
1 |
superseded
|
| 35 |
830757130 |
TUBING (.312) (70.00 Inches Bulk) (7 IN.) [0G960499] & Below
|
1 |
superseded
|
| 36 |
816296Q1 |
FILTER Fuel [0G960499] & Below
|
1 |
superseded
|
| 37 |
49542 |
CLAMP [0G960499] & Below
|
1 |
disc.
|
| 38 |
830756109 |
HOSE (57.00 Inches Bulk) (6-1/2 IN.) [0G960499] & Below
|
1 |
superseded
|
| 4 |
816311T |
TIE STRAP (8.00 Inches)
|
AR |
|
| 5 |
8189941 |
CHECK VALVE
|
1 |
|
| 6 |
82381335 |
TUBING (15.00 Inches Bulk) (6 IN.)
|
1 |
|
| 7 |
818992 |
CONNECTOR
|
1 |
|
| 8 |
830756109 |
HOSE (57.00 Inches Bulk) (5 IN.)
|
2 |
superseded
|
| 9 |
830756109 |
HOSE (57.00 Inches Bulk) (4-1/2 IN.)
|
1 |
superseded
|
