Throttle Body and Flame Arrestor
Parts (22)
| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 8M0207823 |
COVER COVER |
1 | |
| 10 | 807054 |
ВИНТ (0.250-20 x 1.00) SCREW (.250-20 x 1.00) |
4 | discontinued |
| 11 | 807133 |
ШПИЛЬКА (0.250 x 1.750) STUD (.250 x 1.750) |
1 | |
| 12 | 20533 |
ШАЙБА WASHER |
1 | |
| 13 | 826709109 |
ГАЙКА (0.250-28), нержавеющая сталь NUT (.250-28) Stainless Steel |
1 | |
| 14 | 8M0224472 |
PLATE PLATE |
1 | |
| 15 | 41610 |
ПРОКЛАДКА GASKET |
1 | |
| 16 | NSS |
НЕ ПРОДАЕТСЯ ОТДЕЛЬНО Hose Bibb NOT SOLD SEPARATE Hose Bibb |
1 | |
| 17 | NSS |
НЕ ПРОДАЕТСЯ ОТДЕЛЬНО Plug NOT SOLD SEPARATE Plug |
1 | |
| 18 | 861388 |
КРОНШТЕЙН Трос газа BRACKET Throttle Cable |
1 | |
| 19 | 74824 |
ВИНТ (0.312-18 x 1.250) SCREW (.312-18 x 1.250) |
2 | |
| 2 | NSS |
НЕ ПРОДАЕТСЯ ОТДЕЛЬНО DECAL NOT SOLD SEPARATE DECAL |
1 | |
| 20 | 860132 |
ВИНТ (0.312-18 x 1.250) SCREW (.312-18 x 1.250) |
2 | discontinued |
| 21 | 20084 |
ШАЙБА (0.328 x 0.562 x 0.062) WASHER (.328 x .562 x .062) |
4 | |
| 22 | 97477A3 |
КОМПЛЕКТ ШПИЛЕК STUD KIT |
1 | |
| 3 | 69056 |
ШАЙБА (0.255 x 0.620 x 0.030), нержавеющая сталь WASHER (.255 x .620 x .030) Stainless Steel |
1 | |
| 4 | 826709109 |
ГАЙКА (0.250-28), нержавеющая сталь NUT (.250-28) Stainless Steel |
1 | |
| 5 | 26907 |
ШАЙБА WASHER |
1 | discontinued |
| 6 | 8M0188487 |
FLAME ARRESTOR FLAME ARRESTOR |
1 | |
| 7 | 8M0225007 |
STUD 8M0199118 STUD 8M0199118 |
1 | |
| 8 | 8M0224471 |
THROTTLE BODY THROTTLE BODY |
1 | |
| 9 | 41610 |
ПРОКЛАДКА GASKET |
3 |
