| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 8M6001495 |
ФИТИНГ 0.375" ORFS – короткий (Pressure) FITTING .375 Inch ORFS - Short (Pressure) |
1 | |
| 10 | 815504206 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
1 | |
| 11 | 8M0131184 |
ФИТИНГ Отверстие (0,078) 13/16 дюйма Actuator Return Hose Optional FITTING Orifice (0.078) 13/16 inch Actuator Return Hose Optional |
AR | |
| 12 | 892525 |
КОЛПАК CAP-FITTING |
1 | |
| 13 | 8M6004688 |
ЗАГЛУШКА 13/16-16 ДЛЯ ОТВЕРСТ. CAP-13/16-16 ORFS |
1 | disc. |
| 14 | 892523 |
ФИТИНГ FITTING |
1 | |
| 15 | 8M6004587 |
КАЛИБР 13/16-16 ДЛЯ ОТВЕРСТ. PLUG-13/16-16 ORFS |
1 | disc. |
| 16 | 8M0147795 |
HOSE ADAPTOR Male Saginaw-Flare to Male ORFS Use to connect Design I & II pressure hoses to pump 8M0148159 HOSE ADAPTOR Male Saginaw-Flare to Male ORFS Use to connect Design I & II pressure hoses to pump 8M0148159 |
AR | |
| 17 | 89879 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (0.301 x 0.064) O-RING (.301 x .064) |
1 | |
| 18 | 8M0152467 |
HOSE ADAPTOR 30 in. Female ORFS to Female Saginaw-Flare Use to connect Gen 2 pressure hoses to pump 8M0131261, 8M0131262, or 8M0131263 HOSE ADAPTOR 30 in. Female ORFS to Female Saginaw-Flare Use to connect Gen 2 pressure hoses to pump 8M0131261, 8M0131262, or 8M0131263 |
AR | |
| 2 | 8M0047399 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО O-RING |
2 | |
| 3 | 8M6001497 |
ФИТИНГ 0.375" ORFS – длинный (Pressure) FITTING .375 Inch ORFS - Long (Pressure) |
1 | |
| 4 | 8M0047399 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО O-RING |
2 | |
| 5 | 8M0031539 |
ФИТИНГ – КОЛЕНЧАТЫЙ ПАТРУБОК 90 ГРАД. 0.375" ORFS (Pressure) FITTING - ELBOW 90 DEG .375 Inch ORFS (Pressure) |
1 | |
| 6 | 8M0047399 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО O-RING |
1 | |
| 7 | 892438002 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 892438003 |
РУКАВ (Return) HOSE (Return) |
1 | disc. |
| 7 | 892438004 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 892438005 |
HOSE (Return) HOSE (Return) |
1 | disc. |
| 7 | 892438006 |
HOSE (Return) HOSE (Return) |
1 | disc. |
| 7 | 892438007 |
HOSE (Return) HOSE (Return) |
1 | disc. |
| 7 | 892438008 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 892438010 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 892438012 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 892438014 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 892438016 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 892438018 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 892438020 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 892438022 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 892438024 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 8M2019252 |
HOSE (Return) HOSE (Return) |
1 | |
| 7 | 8M2019253 |
HOSE (Return) HOSE (Return) |
1 | disc. |
| 7 | 8M2019254 |
HOSE (Return) HOSE (Return) |
1 | disc. |
| 7 | 8M0148070 |
RETURN HOSE 32 ft. (Return) RETURN HOSE 32 ft. (Return) |
1 | |
| 8 | 8M6004888 |
PRESSURE HOSE 1.5 ft. (Pressure) PRESSURE HOSE 1.5 ft. (Pressure) |
1 | |
| 8 | 8M0077082 |
ШЛАНГ В СБОРЕ 0.375" ORFS – 2 фт. в длину (Pressure) HOSE ASSEMBLY .375 Inch ORFS- 2 Foot Length (Pressure) |
1 | |
| 8 | 8M0077083 |
ШЛАНГ В СБОРЕ 0.375" ORFS – 3 фт. в длину (Pressure) HOSE ASSEMBLY .375 Inch ORFS- 3 Foot Length (Pressure) |
1 | |
| 8 | 8M0077084 |
ШЛАНГ В СБОРЕ 0.375" ORFS – 4 фт. в длину (Pressure) HOSE ASSEMBLY .375 Inch ORFS- 4 Foot Length (Pressure) |
1 | |
| 8 | 8M0148098 |
PRESSURE HOSE 5 ft. (Pressure) PRESSURE HOSE 5 ft. (Pressure) |
1 | |
| 8 | 8M0148099 |
PRESSURE HOSE 6 ft. (Pressure) PRESSURE HOSE 6 ft. (Pressure) |
1 | |
| 8 | 8M0148100 |
PRESSURE HOSE 7 ft. (Pressure) PRESSURE HOSE 7 ft. (Pressure) |
1 | |
| 8 | 892825008 |
РУКАВ (8 фт.) (Pressure) HOSE (8 Feet) (Pressure) |
1 | |
| 8 | 892825010 |
РУКАВ (10 фт.) (Pressure) HOSE (10 Feet) (Pressure) |
1 | |
| 8 | 892825012 |
РУКАВ (12 фт.) (Pressure) HOSE (12 Feet) (Pressure) |
1 | |
| 8 | 892825014 |
РУКАВ (14 фт.) (Pressure) HOSE (14 Feet) (Pressure) |
1 | |
| 8 | 892825016 |
РУКАВ (16 фт.) (Pressure) HOSE (16 Feet) (Pressure) |
1 | |
| 8 | 892825018 |
РУКАВ (18 фт.) (Pressure) HOSE (18 Feet) (Pressure) |
1 | |
| 8 | 892825020 |
РУКАВ (20 фт.) (Pressure) HOSE (20 Feet) (Pressure) |
1 | |
| 8 | 892825022 |
РУКАВ (22 фт.) (Pressure) HOSE (22 Feet) (Pressure) |
1 | |
| 8 | 892825024 |
РУКАВ (24 фт.) (Pressure) HOSE (24 Feet) (Pressure) |
1 | |
| 8 | 892825026 |
РУКАВ (26 фт.) (Pressure) HOSE (26 Feet) (Pressure) |
1 | |
| 8 | 8M0148101 |
PRESSURE HOSE 28 ft. (Pressure) PRESSURE HOSE 28 ft. (Pressure) |
1 | disc. |
| 8 | 8M0148102 |
PRESSURE HOSE 30 ft. (Pressure) PRESSURE HOSE 30 ft. (Pressure) |
1 | |
| 8 | 8M0148103 |
PRESSURE HOSE 32 ft. (Pressure) PRESSURE HOSE 32 ft. (Pressure) |
1 | disc. |
| 9 | 8M0150604 |
PUMP TO BULKHEAD/HELM KIT 2 Ft PUMP TO BULKHEAD/HELM KIT 2 Ft |
AR | |
| 9 | 8M0150605 |
PUMP TO BULKHEAD/HELM KIT 3 Ft PUMP TO BULKHEAD/HELM KIT 3 Ft |
AR | |
| 9 | 8M0150606 |
PUMP TO BULKHEAD/HELM KIT 4 Ft PUMP TO BULKHEAD/HELM KIT 4 Ft |
AR | |
| 9 | 8M0150607 |
PUMP TO BULKHEAD/HELM KIT 5 Ft PUMP TO BULKHEAD/HELM KIT 5 Ft |
AR | |
| 9 | 8M0150608 |
PUMP TO BULKHEAD/HELM KIT 6 Ft PUMP TO BULKHEAD/HELM KIT 6 Ft |
AR | |
| 9 | 8M0150610 |
PUMP TO BULKHEAD/HELM KIT 7 Ft PUMP TO BULKHEAD/HELM KIT 7 Ft |
AR | |
| 9 | 8M0150612 |
PUMP TO BULKHEAD/HELM KIT 8 Ft PUMP TO BULKHEAD/HELM KIT 8 Ft |
AR | |
| 9 | 8M0150613 |
PUMP TO BULKHEAD/HELM KIT 10 Ft PUMP TO BULKHEAD/HELM KIT 10 Ft |
AR | |
| 9 | 8M0150614 |
PUMP TO BULKHEAD/HELM KIT 12 Ft PUMP TO BULKHEAD/HELM KIT 12 Ft |
AR | |
| 9 | 8M0150615 |
PUMP TO BULKHEAD/HELM KIT 14 Ft PUMP TO BULKHEAD/HELM KIT 14 Ft |
AR | |
| 9 | 8M0150616 |
PUMP TO BULKHEAD/HELM KIT 16 Ft PUMP TO BULKHEAD/HELM KIT 16 Ft |
AR | |
| 9 | 8M0150617 |
PUMP TO BULKHEAD/HELM KIT 18 Ft PUMP TO BULKHEAD/HELM KIT 18 Ft |
AR | |
| 9 | 8M0150618 |
PUMP TO BULKHEAD/HELM KIT 20 ft PUMP TO BULKHEAD/HELM KIT 20 ft |
AR | |
| 9 | 8M0150619 |
PUMP TO BULKHEAD/HELM KIT 22 FT PUMP TO BULKHEAD/HELM KIT 22 FT |
AR | |
| 9 | 8M0150620 |
PUMP TO BULKHEAD/HELM KIT 24 FT PUMP TO BULKHEAD/HELM KIT 24 FT |
AR | |
| 9 | 8M0150621 |
PUMP TO BULKHEAD/HELM KIT 26 FT PUMP TO BULKHEAD/HELM KIT 26 FT |
AR | |
| 9 | 8M0150622 |
PUMP TO BULKHEAD/HELM KIT 28 FT PUMP TO BULKHEAD/HELM KIT 28 FT |
AR | |
| 9 | 8M0150623 |
PUMP TO BULKHEAD/HELM KIT 30 FT PUMP TO BULKHEAD/HELM KIT 30 FT |
AR | |
| 9 | 8M0150624 |
PUMP TO BULKHEAD/HELM KIT 32 FT PUMP TO BULKHEAD/HELM KIT 32 FT |
AR |
