| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8M0118178 |
HOUSING Driveshaft- Long
|
1 |
|
| 1 |
852421T08 |
HOUSING Driveshaft - Short
|
1 |
|
| 10 |
816311T |
TIE STRAP (8.00 Inches) Long
|
1 |
|
| 11 |
892286 |
CAP Long
|
1 |
|
| 12 |
8M0043364 |
BUMPER
|
1 |
|
| 13 |
823984 |
STUD (M10 x 50)
|
1 |
|
| 14 |
856774 |
WASHER (.406 x .750 x .105) Stainless Steel
|
1 |
superseded
|
| 15 |
40140 |
NUT (M10)
|
1 |
|
| 16 |
897971A01 |
TUBE/SEAL KIT Water - Long
|
1 |
|
| 16 |
897970A01 |
TUBE/SEAL KIT Water - Short
|
1 |
|
| 17 |
8M0109684 |
SEAL Water Tube, Upper
|
1 |
superseded
|
| 18 |
828529 |
GUIDE
|
1 |
|
| 19 |
8M4503628 |
PLATE Driveshaft Housing
|
1 |
|
| 2 |
825220T06 |
PIPE Exhaust Long
|
1 |
|
| 2 |
8M0161064 |
PIPE Exhaust Short
|
1 |
|
| 20 |
1993325 |
SCREW (M10 x 25 MM)
|
1 |
|
| 21 |
856774 |
WASHER (.406 x .750 x .105) Stainless Steel
|
4 |
superseded
|
| 22 |
4000380 |
SCREW (M10 x 45)
|
4 |
|
| 3 |
88960845 |
SCREW (M8 x 45)
|
5 |
|
| 4 |
824459110 |
SCREW (M8 x 110) Stainless Steel
|
8 |
|
| 5 |
8288181 |
PLUG Drain
|
1 |
|
| 6 |
8M0007119 |
SEAL Drain Plug
|
1 |
superseded
|
| 7 |
826276 |
BUMPER
|
1 |
|
| 8 |
828817001 |
GROMMET Long
|
1 |
superseded
|
| 9 |
13035002 |
FITTING Long
|
1 |
superseded
|
