| # | Part Number | Description | Qty | Status |
|---|
| 1 |
812718A1 |
TANK ASSEMBLY Oil
|
1 |
superseded
|
| 10 |
58376 |
SCREW (.164-18 x .375)
|
1 |
|
| 11 |
72761 |
WASHER (.203 x .562 x .060) Stainless Steel
|
1 |
|
| 12 |
818902A1 |
PUMP ASSEMBLY Oil Injection
|
1 |
|
| 13 |
62705 |
O-RING
|
1 |
superseded
|
| 14 |
36390 |
O-RING
|
1 |
|
| 15 |
40011108 |
SCREW (M5 x 20) Stainless Steel
|
2 |
|
| 16 |
19277 |
GEAR Driven
|
1 |
|
| 17 |
19278A2 |
BEARING ASSEMBLY
|
1 |
|
| 18 |
82381329 |
TUBING (12.00 Inches Bulk) (1-1/2)(6 IN.)
|
2 |
superseded
|
| 19 |
821287 |
LINK
|
1 |
disc.
|
| 2 |
828765A2 |
CAP ASSEMBLY
|
1 |
|
| 20 |
817428 |
SOCKET
|
2 |
|
| 21 |
45076 |
NUT (#10-32) Brass
|
1 |
|
| 3 |
8160662 |
SEAL
|
1 |
superseded
|
| 4 |
19299A1 |
VENT ASSEMBLY
|
1 |
|
| 5 |
64871 |
VALVE
|
1 |
|
| 6 |
813644 |
GROMMET
|
1 |
disc.
|
| 7 |
813649 |
BOOT
|
1 |
disc.
|
| 8 |
812890 |
BOOT
|
1 |
superseded
|
| 9 |
12886A6 |
SWITCH ASSEMBLY
|
1 |
|
