| # | Part Number | Description | Qty | Status |
|---|
| - |
883599A02 |
GASKET SET Powerhead
|
1 |
|
| 1 |
825228T27 |
ADAPTER PLATE ASSEMBLY
|
1 |
disc.
|
| 10 |
816311T |
TIE STRAP (8.00 Inches)
|
3 |
|
| 11 |
66301 |
SEAL Oil
|
1 |
|
| 12 |
859594 |
BUSHING [1C139355] & Below
|
1 |
|
| 13 |
4007455 |
SCREW (M6 x 55)
|
1 |
|
| 14 |
892320001 |
GASKET
|
1 |
superseded
|
| 15 |
845746 |
O-RING
|
1 |
|
| 16 |
40011128 |
SCREW (M6 x 20) Stainless Steel
|
3 |
superseded
|
| 17 |
893765 |
PLATE Top Oil Pickup
|
1 |
|
| 18 |
855228 |
CLAMP
|
2 |
|
| 19 |
854793 |
HOSE Oil Pickup
|
1 |
|
| 2 |
23784 |
PIN Dowel
|
4 |
|
| 20 |
893700 |
BAFFLE Oil Pick-up
|
1 |
|
| 21 |
881872A1 |
BODY Oil Pressure Relief
|
1 |
superseded
|
| 22 |
8M0021330 |
PLUG (M18)
|
1 |
|
| 23 |
899145 |
CLIP Tie Strap
|
1 |
|
| 24 |
816311T |
TIE STRAP (8.00 Inches)
|
AR |
|
| 25 |
830756109 |
HOSE (57.00 Inches Bulk) Cut to 17 Inches
|
1 |
superseded
|
| 26 |
291112 |
FITTING
|
1 |
|
| 3 |
8M0026249 |
DIPSTICK TUBE ASSEMBLY Plastic
|
1 |
|
| 4 |
8M0008708 |
O-RING
|
1 |
|
| 5 |
825990 |
DIPSTICK
|
1 |
superseded
|
| 6 |
4006731 |
SCREW (M6 x 16)
|
1 |
|
| 7 |
822464 |
PLUG
|
2 |
|
| 8 |
19565002 |
GROMMET
|
1 |
|
| 9 |
629101 |
FITTING Elbow - 90 Degree (.125-27)
|
1 |
|
