| # | Part Number | Description | Qty | Status |
|---|
| 1 |
896963 |
NUT (M12)
|
2 |
|
| 10 |
893590T04 |
SWIVEL TUBE Long
|
1 |
superseded
|
| 10 |
850175T03 |
SWIVEL TUBE ASSEMBLY Short Jet
|
1 |
superseded
|
| 11 |
88238A4 |
CABLE ASSEMBLY
|
1 |
superseded
|
| 12 |
88238A13 |
CABLE ASSEMBLY Ground Long
|
1 |
superseded
|
| 12 |
8M0007781 |
CABLE ASSEMBLY Ground Jet
|
1 |
superseded
|
| 13 |
892086120 |
SCREW (M10 x 120)
|
2 |
superseded
|
| 14 |
893703 |
STRAP Lower Mount
|
1 |
|
| 15 |
878607 |
SCREW (#10-16 x .375)
|
3 |
|
| 16 |
40140 |
NUT (M10)
|
2 |
|
| 17 |
8M0001163 |
LINK ROD Non Handle
|
1 |
superseded
|
| 18 |
823919 |
SCREW (.375-24 x 1.500) Non Handle
|
1 |
|
| 19 |
71970 |
WASHER (.390 x .546 x .12) Non Handle
|
1 |
superseded
|
| 2 |
893773002 |
STRAP Upper Mount
|
1 |
|
| 20 |
37828 |
WASHER (.390 x .625 x .062) Stainless Steel Non Handle
|
2 |
|
| 21 |
8M0042636 |
NUT (.375-24) Brass Non Handle
|
1 |
superseded
|
| 22 |
826709113 |
NUT (.375-24) Stainless Steel Non Handle
|
1 |
superseded
|
| 23 |
816667F3 |
BRACKET Ride-Guide Non Handle
|
1 |
superseded
|
| 24 |
8M0009820 |
TAB WASHER Non Handle
|
1 |
|
| 24 |
816669F1 |
TAB WASHER Jet
|
1 |
superseded
|
| 25 |
4000377 |
SCREW (M10 x 30) Non Handle
|
2 |
|
| 26 |
4002319 |
WASHER
|
2 |
|
| 3 |
893655T |
MOUNT Upper
|
2 |
superseded
|
| 4 |
40011128 |
SCREW (M6 x 20) Stainless Steel
|
8 |
superseded
|
| 5 |
826658 |
BUMPER
|
2 |
superseded
|
| 6 |
89531 |
RING Retaining
|
1 |
|
| 7 |
825222T03 |
ARM Steering
|
1 |
superseded
|
| 8 |
898835001 |
SCREW (M12 x 154)
|
2 |
|
| 9 |
8279971 |
SPACER Long
|
1 |
|
| 9 |
8279973 |
SPACER Jet
|
1 |
|
