| # | Part Number | Description | Qty | Status |
|---|
| 1 |
892869T |
PLATE Coil
|
1 |
|
| 10 |
82129125 |
SCREW (M6 x 25 MM)
|
3 |
|
| 11 |
8M0024807 |
CLIP
|
3 |
|
| 12 |
826802T36 |
HARNESS ASSEMBLY Trim
|
1 |
|
| 13 |
856954 |
BUSHING
|
3 |
|
| 14 |
834985 |
GROMMET
|
3 |
superseded
|
| 15 |
858414A3 |
CABLE ASSEMBLY
|
1 |
|
| 16 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
1 |
superseded
|
| 17 |
82129114 |
SCREW (M6 x 14)
|
1 |
|
| 18 |
88552525 |
SCREW (M6 x 25 MM) Stainless Steel
|
3 |
superseded
|
| 19 |
4002316 |
WASHER (6.60 X 17.0 X 1.5SS)
|
3 |
superseded
|
| 2 |
879984T00 |
COIL Ignition
|
4 |
superseded
|
| 20 |
8M0024808 |
J-CLIP
|
1 |
|
| 3 |
881908T |
CABLE SET
|
1 |
|
| 4 |
892863001 |
SPACER
|
8 |
superseded
|
| 5 |
82129145 |
SCREW (M6 x 45)
|
8 |
|
| 6 |
882751A1 |
RELAY ASSEMBLY
|
3 |
superseded
|
| 7 |
828102 |
BRACKET
|
3 |
superseded
|
| 8 |
818967 |
GROMMET
|
3 |
|
| 9 |
818968 |
BUSHING
|
3 |
superseded
|
